Specifications

Source

• Light Source Type: LED
• Light Source Quantity: 14
• Light Source Power: 12 W
• LED Colour Type: RGBW
• Refresh Rate: 900 Hz
• Refresh Rate (Min.): 900 Hz
• Refresh Rate (Max.): 9 kHz
• Luminous Flux (Total): 3900 lm

Optical

• Beam Angle Min. (Circular): 8°
• Beam Angle Max. (Circular): 40°
• Zoom Type: Motorised
• Zoom Minimum: 8°
• Zoom Maximum: 40°

Control and Programming

• Control Mode: Auto, DMX, Manual, Master Slave
• DMX Channels: 3, 4, 5, 6, 7, 12, 17
• Protocols: DMX
• Display: 7-segment

Dynamic Effects

• Dimmer: 0-100 %
• Strobe: 0-20 Hz

Electrical Specifications and Connections

• Power Supply: 100-240 VAC 50-60 Hz
• Power Consumption: 200 W
• Power Connector In: powerCON TRUE1
• Power Connector Out: powerCON TRUE1
• DMX Connector: Dedicated 3P IP65 In/Out, Dedicated 5P IP65 In/Out
• DMX Connector In: Dedicated 3P IP65, Dedicated 5P IP65
• DMX Connector Out: Dedicated 3P IP65, Dedicated 5P IP65
• Cable Length: 1.5 m

Mechanical Specifications

• Length (mm): 250 mm
• Width (mm): 275 mm
• Height (mm): 375 mm
• Weight: 8.4 kg
• IP Rating: IP65
• Housing: Aluminium die-cast
• Colour: Black

Product Properties

• Cooling: Convection

Rigging

• Mounting Options: Clamp, Surface
• Safety Attachment: Yes

Thermal Specifications

• Maximum Ambient Temperature: 40 °C
• Minimum Operating Temperature: -10 °C

Included Items

• Included Cables: powerCON TRUE1 cable
• Included Accessories: User Manual
• Included Rigging: Bracket, Safety Cable
