PROLIGHTS Smart Bat

Features:

• Wireless operated: through proprietary wireless DMX protocol or SmartColors app for IOS and Android devices
• Long lasting battery life: 12 h in colour changing mode / 8 h in full
• Available in black or white
• Adjustable foot support for tilt regulation (up to 20°)

LIGHT SOURCE

• Source: 4x8W RGBW LEDs
• Luminous flux: 1'127lm
• Lux: 833lx @3 m full
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 13°
• Field angle: 30°
• Lens diameter: 42mm
• Additional optics: 25° and 45° optional

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• White presets: 3.200 K ~ 10.000K
• Colour wheel: virtual colour wheel with macros

DYNAMIC EFFECTS

• Static mode: selection of static colour
• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment

BODY

• Tilt angle: ° adjustable foot support for tilt regulation (up to 20°)
• Body: sturdy die-cast aluminium body
• Body colour: black, white finishing available

CONTROL

• Protocols: DMX512
• DMX channels: 4 / 6 / 10channel
• Wireless Control: integrated, proprietary protocol compatible with WIFIBOX, WDBOX
• Display: LED display user interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• IR: infrared sensor controlled by remote
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 25 Hz, electronic
• Operating temperature: 0° ~ +40°
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 30W
• Max power consumption (at 120V): 31W

BATTERY

• Battery: 24V lithium
• Estimated battery life in colour change mode up to: 12h
• Estimated battery life in full-mode up to: 8h
• Re-charge connection: power cable
• Re-charge time: 5h/max
• Battery status: LED battery status indicator

PHYSICAL

• IP rating: 33
• Cooling: passive cooling and fan-free
• Suspension and fixing: M12 threaded insert for easy clamp installation
• Signal connection: XLR 3p IN/OUT connectors
• Power connection: IEC IN/OUT connectors
• Dimensions (WxHxD): 138x184x145mm
• Weight: 3,4kg

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x SMARTBAT
• 1 x 1,5 meters BARE END - IEC power cable
• 1 x LUMIPARIRCH
• User Manual
