Showtec Phantom 3R Hybrid

• 140 W Moving Head sowohl für Spot-, Wash als auch Beam-Effekte
• Motorisierter Zoom, Fokus und Frost
• 16 Facetten lineare & 8 Facetten zirkuläre überlappende Prismen
• Motorisierter Zoom
• 12 dichroitische Farben + Weiß

Source

• Light Source Type: Discharge
• Light Source Quantity: 1
• Life Expectancy: 6000 h
• Lumen Total: 9200 lm
• CRI: 70
• CCT: 8600 K
• Source Warm-up Time: 3 min
• Source Hot Restart Time: 5 min

Optical

• Beam Angle Circular (min): 3 °
• Beam Angle Circular (max): 20 °
• Zoom Type: Motorized
• Zoom Minimum: 3 °
• Zoom Maximum: 20 °
• Frost: Yes
• Focus: Motorized

Control and Programming

• Control Mode: Auto, DMX, Manual, Master Slave, Sound
• DMX Channels: 14, 19
• Protocols: DMX
• Wireless: Optional
• Display: LCD

Dynamic Effects

• Dimmer: 0-100%
• Strobe: 0-20Hz
• Shutter: Yes
• Prism 1: Circular
• Prism 2: Linear
• Prism Overlay: Yes
• Prism Index & Rotate: No
• Colour System: Colour Wheel
• Dichroic Colourwheel 1: 12 + Open
• Gobo System: Glass + Metal
• Gobo Wheel Index & Rotate: Yes
• Gobo Wheel 1: 16 + Open
• Gobo Wheel 2: 8 + Open
• Gobo Size: 13.75 mm
• Image Size: 11.75 mm

Movement

• Pan: 540 °
• Tilt: 260 °
• Pan/Tilt Resolution: 16 bit

Electrical Specifications and Connections

• Power Supply: 100-240 VAC 50-60Hz
• Power Consumption: 270 W
• Fuse: 5 A
• Power Connector in: ProPower Blue
• Power Connector out: ProPower Grey
• DMX Connector: XLR 3P In/Out
• DMX Connector in: XLR 3P
• DMX Connector out: XLR 3P

Mechanical Specifications

• Length (mm): 325 mm
• Width (mm): 210 mm
• Height (mm): 505 mm
• Weight: 16,7 kg
• IP Rating: IP20(indoor use only)
• Housing: Metal, Plastic
• Colour: Black

Product Properties

• Cooling: Axial fan

Rigging

• Mounting Options: Quick Lock
• Safety Attachment: Yes

Thermal Specifications

• Maximum Ambient Temperature: 40 °C
• Maximum Surface Temperature: 70 °C
• Minimum distance till objects: 10 m

Certifications/Qualifications

• Reference Standard: CE

Included Items

• Included Cables: PowerCon cable
• Included Rigging: Quick Lock Bracket
