Showtec Performer Profile Mini 5600 K

Source

• Light Source Type: LED
• Light Source Quantity: 1
• Light Source Power: 30 W
• LED Colour Type: CW
• Lumen Total: 1600 lm
• CCT Maximum: 5600 K

Control and Programming

• Control Mode: DMX
• DMX Channels: 1
• Protocols: DMX, RDM

Dynamic Effects

• Dimmer: 0-100%

Electrical Specifications and Connections

• Power Supply: 100-240 VAC 50-60Hz
• Power Consumption: 25 W
• Power Connector in: Internal Powerlink with custom power connector
• DMX Connector: XLR 3P In/Out
• DMX Connector in: XLR 3P
• DMX Connector out: XLR 3P

Mechanical Specifications

• Length (mm): 345 mm
• Width (mm): 130 mm
• Height (mm): 231 mm
• Weight: 1,3 kg
• IP Rating: IP20(indoor use only)
• Housing: Aluminum Die-cast
• Colour: Black

Product Properties

• Cooling: Axial fan

Rigging

• Safety Attachment: Yes

Thermal Specifications

• Maximum Ambient Temperature: 70 °C
• Maximum Surface Temperature: 50 °C
• Minimum Operating Temperature: -10 °C

Certifications/Qualifications

• Reference Standard: CE

Included Items

• Included Cables: Fixed Cable
