Professional electronic viewfinder designed for precise framing control in any shooting condition. Designed for direct integration with the URSA Cine line of cameras, it combines a high-brightness HDR display with a high-quality optical system to ensure sharp, accurate viewing even outdoors and in bright lighting.
It connects to the camera via USB-C, which provides video, power, and control, simplifying installation and reducing cabling. It includes assignable function buttons, a proximity sensor for automatic display activation, and diopter adjustment to fit any eye. The rugged construction and adjustable mount ensure comfortable use on both cinema rigs and shoulder-mounted setups.
Designed for professionals who require the utmost precision in focus and exposure, the URSA Cine EVF is an essential accessory for getting the most out of URSA Cine cameras for filmmaking and broadcast.
Technical characteristics
Connections
Video inputs: USB-C
Power input: USB-C
Data input/output: USB-C
Computer interface: USB-C for software updates
Features
Display resolution: full 1920 x 1080
Dots: 6.22 million
Display type: OLED
Frame rates: up to 60 fps
Focus: 4 element diopter
Diopter range: -5 to +5
Controls: record button, exposure button, zoom button, 3 x assignable VF buttons
Overlays: built in overlay display processor and top mounted buttons
Eyepiece: can be tilted vertically and extended for left or right eye use
Tally: LED tally light
Mounting options: fully adjustable EVF mounting kit included. Blackmagic URSA Cine Handle is required for mounting to Blackmagic URSA Cine and Blackmagic PYXIS 6K cameras. Blackmagic URSA Cine EVF Extension compatible with standard extended viewfinder supports
Metadata support: displays and sends camera data and settings over USB to Blackmagic URSA Cine and Blackmagic PYXIS 6K cameras
Operating systems
Mac: Mac 13.0 Ventura, Mac 14.0 Sonoma or later
Windows: Windows 10 and 11
Power requirements
Power: powered over USB-C
Environmental specifications
Operating temperature: 0 to 40 °C
Storage temperature: -20 to 45 °C
Relative humidity: 0% to 90% non-condensing
What's included
Blackmagic URSA Cine EVF
Blackmagic URSA Cine EVF rotating bracket with 19 mm carbon fibre rod
Blackmagic URSA Cine EVF bracket rod mount
Blackmagic URSA Cine EVF extension
2 Short carbon fibre 15 mm rods
1 x Long USB viewfinder cable. Right angle to straight
1 x Short USB viewfinder cable. Right angle to straight
1 x Short USB viewfinder cable. Right angle to right angle
