Rondson AM 30A

Integrated amplifier / mixer with 100 V line output, 30 W power. In addition to the 25, 70 and 100 V loudspeaker outputs, there is a low impedance 8 ohm output. Operation with 230 VAC or 24 VDC mains.

2 X balanced microphone inputs (jack / XLR), MIC 2 and MIC 3. These 3 inputs are switchable to Phantom power (internal intervention), MIC 3 switchable to line, an acoustic signal (2 and #34;ding dong and #34; tones) can be activated by the MIC 1 microphone inserted into the 5-pole DIN socket (PA 100D microphone station) or into the stereo jack socket on the front panel (PA 100J console)

• Main features
• 1 X balanced DIN /jack / XLR microphone input MIC 1 (priority) via Talk-Over or remote control
• 1 X telephone input, emergency message, super priority
• 2 X AUX RCA inputs (tuner, CD, etc.)
• 1 X input and output for equalizer or amplifier
• 1 X recording output
• Speaker outputs on terminal block BI 8 ohm, HI 25, 70 or 100 V
• Cooling fan
