Rondson AM 240C Amplifiers
  • -25%
  • New

Rondson AM 240C


€1,238.00
€929.00 -25%
Tax included
Lowest price within the last 30 days: €929.00

240 W integrated amplifiers, 100 V line


Qty

In Stock

Delivery

Do You want Your order by Monday, 25/05/2026? Order within 11 hours and 5 minutes

Free shipping


wishlist

Rondson AM 240C



240 W mixer / amplifier including 25 / 50 / 100 V and 8 ohm (low impedance) speaker outputs. It works on mains (230 VAC) or 24 VDC.

N.B. All three inputs can be switched to phantom powered microphones (internal operation), MIC 3 can be switched online, a beep (2 and #34;ding dong and #34; tones) can be triggered from the MIC 1 microphone connected to the DIN socket 5 poles (PA 100D Call Microphone Panel) or to the stereo socket on the front panel (PA 100J Panel).

  • Main features
  • 1 Balanced DIN / jack / XLR input for MIC 1 balanced microphone (priority) via Talk Over or remote control
  • 2 Balanced microphone inputs (jack / XLR) for MIC 2 and MIC 3
  • 1 Telephone input, emergency message with absolute priority
  • 2 RCA AUX inputs (tuner, CD, etc.)
  • 1 Input and output for equalizer or amplifier
  • 1 Recording output
  • Low impedance 8 ohm, high impedance 25 / 70 / 100 V speaker outputs on terminal block
  • Cooling fan
  • Type: amplifier / preamplifier
  • Power supply: 115 - 230 VAC 50/60 Hz +-10% - switchable 24 VDC (maximum deviation 10%)
  • Output power: 240 WRMS
  • Loudpeaker outputs: 8 ohm - 25 / 70 / 100 V
  • Output recording - TAPE: 350 mV, 4.75 kohm
  • Line output - PRE OUT: 1 V, 600 ohm
  • Inputs: MIC 1 to 3: 1 mV, 250 ohm symmetrical Phantom powering configurable
  • AUX 1: 200 mV, 47 kohm, asymmetrical
  • AUX 2: 500 mV, 47 kohm, asymmetrical
  • Line (MIC 3): 200 mV, 47 kohm, symmetrical
  • TEL: 0.1 to 1 V, 600 ohm, symmetrical, adjustable
  • Power in: 1 V, 47 kohm, asymmetrical
  • Frequency response: MIC 1 - 3: 60 Hz - 15 kHz +-3 dB
  • AUX 1 - 2: 60 Hz - 15 kHz +-3 dB
  • TEL: 100 Hz - 15 kHz +-3 dB
  • Total harmonic distortion (THD): less than 1% at 1 kHz at RMS power
  • S/N ratio: All CCW volume settings: 75 dB below rated power
  • MIC 1 to 3: 60 dB below RMS power
  • AUX 1 - 2: 70 dB below RMS power
  • TEL: 70 dB below RMS power
  • Tone settings: bass: +-10 dB at 100 Hz, treble: +- 10 dB at 10 kHz
  • Settings: MIC 1 to 3: volume control
  • AUX 1 - 2: volume control MASTER volume control
  • Tone control: bass and treble
  • TEL: input level
  • MIC 3 (line/MIC): switch
  • Chime: inter. ON/OFF
  • 115 - 230 V: voltage switch
  • Consumption: from mains: 720 W
  • Battery: 16 A
  • Chime: 2 tones Ding Dong preceding 1 microphone call
  • Priority: by detection / MIC 1 connected to DIN, Jack or XLR
  • Priority levels: AUX/CD
  • 1
  • Option montage rack 19 2 U: mounting brackets EQ 2000
  • Dimensions (W x D x H): 43 x 26 x 8.8 cm
  • Weight: 13 kg
