PSSO QDA-6000 MK2 4-channel Amplifier

• Power supply: 100-240 V AC, 50/60 Hz
• Power consumption: 1200 W 1/8 power
• Protection class: Protection class I
• Output power: 4 x 1500 W RMS (4 ohms), 4 x 1000 W RMS (8 ohms), 2 x 3000 W RMS bridged (8 ohms)
• Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug included
• Cable construction: 3 x 1.5 mm² H05VV-F
• Frequency range: 20 - 20000 Hz +-
• S/N ratio: 100 dB
• THD: 0.2 % at 1 kHz
• Cooling: 4 x temperature-controlled fan , air flow from front to rear
• Gain: 32 dB, 36 dB, 41 dB
• Housing color: Black matte
• Circuitry: Class D
• Slew rate: 16 V/µs
• Damping factor: 400
• Crosstalk: 70 dB
• Control elements: Power switch, level control per channel, Input sensitivity switch, mode switch (stereo/parallel/bridged)
• Controls: DC voltage; short-circuit; limiter; softstart; overheat; VHF; overload
• Status LED: Power, signal, level meter, clip, protect; bridged
• Connections: Input: line via 4 x 3-pin XLR (F) mounting version, Output: line via 4 x 3-pin XLR (M) mounting version, Output: speaker via 4 x speaker built-in socket (F)
• Input sensitivity: 0.775 V; 1.4 V; 2.2 V , switchable
• Max. level: Input: +20 dBu, Input: +9 V
• Housing design: (19) 48.3 cm rack installation 2 U
• Mounting depth: 39.8 cm
• Dimensions: Width: 48.3 cm, Depth: 43.5 cm, Height: 8.9 cm
• Weight: 9.15 kg
• Weight: 9.05 kg
• Weight: 0.26 kg

Scope of delivery

• 1 x amplifier
• 1 x power cord
• 4 x foot
• 1 x user manual
