Integrated QuickDMX transceiver for wireless DMX control
Threaded inserts for suspended installation
Cordless, flexible and versatile
Battery operation up to 16h depending on program used
3 LEDs 3 W SMD 8072 3in1 TCL RGB (homogenous color mix)
Dimmer electronic; color blend stepless; color change adjustable; Dimmer speed (step response) adjustable
Strobe effect
The device is cooled by passive convection cooling
Control via IR remote control; DMX; QuickDMX; sound to light via microphone; stand-alone
Preprogrammed in Light'J; LED PC-Control 512; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Flicker-free
With a beam angle of 11°
Multicolor LCD display
Mains input and output for power linking up to 8 units
For application areas such as: Stage; clubs/dancing school; decoration; wedding/gala/events; mobile djs / entertainer; rental; advertisement/Shop window
Silent operation
Application possibility: Standing; suspended
Scope of delivery
1 x spotlight
1 x user manual
1 x power cord
1 x remote control
1 x battery
1 x declaration of conformity
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 25 W
IP classification: IP20
Power connection: Battery/battery pack, Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power output: 1 x IEC connector (F) mounting version
Battery pack type: 1 x lithium ion 11.1 V, 4400 mAh, 48.84 Wh
Battery pack: Battery operation up to 16h depending on program used, Recharging time 3h
Lamp type: LED lamp
LED type: 3 x 3 W SMD 8072 3in1 TCL RGB (homogenous color mix)
Flash rate: 0 - 23 Hz
DMX channels: 3; 5; 8
DMX input: 1 x 3-pin XLR (M) mounting version
DMX output: 1 x 3-pin XLR (F) mounting version
Cooling: Passive convection cooling
Control: IR remote control; DMX; QuickDMX; sound to light via microphone; stand-alone
Preprogrammed in: Light'J; LED PC-Control 512; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Projection: Flicker-free
Carrier frequency: 2.4 GHz
Beam angle: 11°
Beam angle (1/2 peak): 11°
Beam angle (1/10 peak): 24°
Housing color: White
Display type: Multicolor LCD display
Dimensions: Width: 12.1 cm, Depth: 10.8 cm, Height: 14.5 cm
Weight: 1.30 kg
Noise classification: Class 0 (no noise at all)
Cable construction: 3 x 1.0 mm² H05VV-F
Cable length: Approx. 1.2 m
Color: White
Battery: 1 x button cell 3.0 V CR2032 lithium manganese built-in
Special product: Not designed for household room illumination
