DMX and power terminals intelligently designed for easy wiring
1 LED 30 W COB (chip-on-board) ultra violet (UV)
UV effect; strobe effect; wash effect
Integrated show programs
The device is cooled by cooling fan
Control via IR remote control; DMX; sound to light via microphone; stand-alone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for Light'J; Light Captain; Colorchief
Flicker-free
With a beam angle of 18°
With double bracket
4 digit 7-segment LED display
Mains input and output for power linking up to 8 units
For application areas such as: Clubs/dancing school; decoration; mobile djs / entertainer; party room; restaurants, bars and hotels
Application possibility: Standing; suspended; on stand
Scope of delivery
1 x spotlight
1 x power cord
1 x remote control
1 x battery
1 x user manual
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 20 W
IP classification: IP20
Protection class: Protection class II
Power connection: Mains input via IEC connector (M) mounting version power supply cord with safety plug included
Power output: IEC connector (F) mounting version
Fuse: 5 x 20 mm, T 1 A fuse replaceable
Lamp type: LED lamp
LED type: 1 x 30 W COB (chip-on-board) ultra violet (UV)
Flash rate: 0 - 20 Hz
DMX channels: 1; 2; 4
DMX input: 3-pin XLR (M) mounting version
DMX output: 3-pin XLR (F) mounting version
Cooling: 1 x cooling fan
Control: IR remote control; DMX; sound to light via microphone; stand-alone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for: Light'J; Light Captain; Colorchief
Projection: Flicker-free
Beam angle: 18°
Beam angle (1/2 peak): 18°
Beam angle (1/10 peak): 65°
Housing color: Black
Attachment system: Double bracket
Display type: 4 digit 7-segment LED display
Material: Plastic
Dimensions: Width: 21.5 cm, Depth: 12.7 cm, Height: 22.8 cm
Weight: 1.10 kg
Noise classification: Class 3 (clearly perceptible sounds); class 3 (clearly perceptible sounds)
Photobiological safety: Risk Group 0
Diameter mounting holes: 1 x Ø11mm; 2 x Ø10mm
Material: Metal, 1.5 mm
Cable construction: 3 x 0.75 mm² H05VV-F
Cable length: Approx. 1.2 m
Battery: 1 x button cell 3.0 V CR2025 lithium manganese built-in
Special product: Not designed for household room illumination
