Showtec Lampy 40 1U

• 512 channel DMX console
• 10.1" touchscreen with Fixture View and Quick Colour Picker
• Multicolour indicator LEDs and 4 encoder wheels with 1.3" display
• Complete built-in effects engine for easy control
• Second (touch)screen possibility

Control and Programming

• Control Mode: Manual, MIDI
• DMX Channels: 512
• Patch mode: Yes
• Display: LCD, Touch
• Display Size: 10.1 "
• Display External: Yes
• Display External Resolution Width: 1920
• Display External Resolution Height: 1080
• Fixtures: 512
• Buttons: 60
• Cuelists: 90
• Display Encoders: 4
• Display Encoders Type: OLED
• Encoder Wheels: 4
• Faders: 41
• OSC (Open Sound Control): Yes
• Playback Buttons: 40
• Playback Faders: 40
• Playback Pages: 9
• sACN: Optional
• Art-Net: Optional
• Effects Engine: Yes
• Universes: 1

Electrical Specifications and Connections

• Power Supply: 100-240 VAC 50-60Hz
• Power Consumption: 60 W
• Power Connector in: ProPower Blue
• DMX Connector out: XLR 3P, XLR 5P
• Data Connector in: RJ45, USB
• Data Connector out: RJ45, USB
• Midi Connector: Yes
• Ethernet Ports: 1
• Audio Triggers: 3

Mechanical Specifications

• Length (mm): 721 mm
• Width (mm): 345 mm
• Height (mm): 128 mm
• Weight: 11,8 kg
• IP Rating: IP20(indoor use only)
• Housing: Metal, Plastic
• Colour: Black
• Product Properties
• Cooling: Axial fan
• LED Indicators: Operation mode, Output level, Output Level Mimic
• Desklight: Built-in Worklight

Thermal Specifications

• Maximum Ambient Temperature: 40 °C
• Minimum Ambient Temperature: 0 °C
• Minimum Operating Temperature: 0 °C

Certifications/Qualifications

• Reference Standard: CE

Included Items

• Included Cables: ProPower Cable
