Omnitronic EM-312 Entertainment Mixer Installation Mixers
  • -20%

Omnitronic EM-312 Entertainment Mixer

€201.00
€161.00 -20%
Tax included
Lowest price within the last 30 days: €161.00

Microphone line mixer, 6 mono channels + 3 stereo channels

Qty

In Stock

Delivery

Do You want Your order by Tuesday, 07/07/2026? Order within 4 hours and 39 minutes

Free shipping

Compare

wishlist

Omnitronic EM-312 Entertainment Mixer



The EM-312 is a slim rack-mounted 12-channel mixer with 6 mic/line combo inputs and 6 additional line inputs. It has XLR outputs, a 6.3 mm mono output, a stereo RCA recording output, and a 6.3 mm monitoring output for the mic section. The EM-312 offers separate volume controls for all inputs in addition to volume control for the mono output and a master volume control. It has a 3-band equalizer and an adjustable priority function for microphone announcements through channel 1.

Scope of delivery

  • 6 mono mic/line input channels (combo jack), switchable
  • 3 stereo line input channels (RCA)
  • Phantom power can be switched on for each microphone input
  • All input channels with separate level controls and signal LED
  • Adjustable priority circuit for channel 1
  • Balanced stereo XLR outputs and RCA outputs
  • Adjustable monitor output
  • Adjustable mono line output (6.3 mm jack)
  • Master level control, 4-digit stereo LED level meter and 3-band equalizer
  • Additional screw terminals for 24 V DC power input
  • (19) 48.3 cm rack installation 1 U
  • For application areas such as: Installation; restaurants, bars and hotels; clubs/dancing school
  • 1 x device
  • 1 x power cord
  • 4 x foot
  • 1 x user manual
  • Power supply: 230 V AC, 50 Hz, Or, 24V DC
  • Power consumption: 12 W
  • Protection class: Protection class I
  • Power connection: Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided), Mains input via screw terminal
  • Device fuse: 5 x 20 mm, T 0.5 A fuse replaceable
  • Frequency range: 20 - 22000 Hz
  • S/N ratio: 103 dB
  • THD: 0.03 % at 1 kHz
  • Phantom power: 21 V DC or 18 V DC
  • Impedance: Input: mic/line 1.4 kOhm, Input: line 10 kOhm, Output: 120 Ohm
  • Control elements: Power switch, Input sensitivity switch, tone control, level control per channel, Master control
  • Status LED: Power, signal, master level meter, clip
  • Connections: Input: mic/line via 6 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version), Input: line via 3 x stereo RCA, Output: master via 2 x 3-pin XLR, Output: mono via 1 x 6.3 mm jack socket (mono) mounting version, Output: rec. via 1 x stereo RCA
  • Channels: Input chanel: 6 x mono with mic-line switch via Combination socket (XLR/jack), channel control via rotary dial, 3-band tone control EQ 80Hz/2.5kHz/12kHz, Input sensitivity switch, Input chanel: 3 x stereo via RCA, channel control via rotary dial, 3-band tone control EQ 80Hz/2.5kHz/12kHz, Master output: 1 x stereo via XLR, channel control via rotary dial, Master output: 1 x mono via jack, channel control via rotary dial
  • Max. level: Input: microphone -19 dBu, Input: line +21 dBu, Output: +21 dBu
  • Color: Black
  • Housing design: (19) 48.3 cm rack installation 1 U
  • Dimensions: Width: 48.3 cm, Depth: 23 cm, Height: 4.45 cm
  • Weight: 3.04 kg

10007077

Data sheet

Channels
6 channels
Color
Black
