Omnitronic BOB-10A

Scope of delivery

• 1 x bass
• 1 x user manual
• 1 x power cord
• 2 x speaker cable
• 4 x foot
• 4 x screw
• 1 x declaration of conformity

• Power supply: 230 V AC, 50 Hz
• Power consumption: 1060 W
• Protection class: Protection class I
• Power connection: Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
• Power: Rated: 300W RMS LF, Rated: 2x 300W RMS HF
• Frequency range: 45 - 250 Hz
• Sensitivity: 100 dB
• Max. SPL: 125 dB
• DSP: Digital signal processor
• DSP presets: FLAT; DJ; LIVE; SPEECH
• Control: Bluetooth
• Bluetooth device name: Omnitronic BOB
• Attachment system: 2x M20 thread
• Circuitry: Class D
• Control elements: Phase reversal switch, level control per channel, power switch, connect, tone control
• Controls: Softstart; short-circuit; limiter; Overvoltage; overheat
• Status LED: Signal, power, limit, fault, DSP presets
• Connections: Input: line via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version), Output: speaker via 2 x speaker built-in socket (F), Output: line via 1 x 3-pin XLR
• Input channels: 1 x stereo via combination socket or RCA or Bluetooth, channel control via rotary dial
• Speaker: 1 x woofer 10, Basket material: steel, Conematerial: cardboard/paper, Voice coil lows 2
• Type of speaker: Subwoofer
• Type of construction: Vented
• Carrying handle: 4 pc/pcs
• Material: MDF (medium density fiberboard), 15 mm
• Color: White, textured coating
• Dimensions: Width: 30 cm, Depth: 47 cm, Height: 43 cm
• Weight: 17.00 kg
• Cable length: 3 m
