Seamless presentation switcher designed for real-time 4K video processing, fully modular, pre-configured with 6 input cards + 4 output cards on board, 8K ready
Seamless presentation switcher designed for real-time 4K video processing, fully modular, pre-configured with 3 input cards + 4 output cards on board, 8K ready
Seamless presentation switcher designed for real-time 4K video processing, fully modular, pre-configured with 4 input cards + 2 output cards on board, 8K ready
Seamless presentation switcher designed for real-time 4K video processing, fully modular, pre-configured with 2 input cards + 1 output card on board, 8K ready
Variable materials: supports static and dynamic materials, including images, audio, video, scrolling subtitles, PDFs, web pages, live video, number calls, pop-up images, etc.
Flexible scheduling: free scheduling and area-based playback of multiple materials with different modes: playback by day, by week, continuous loop, customized, etc.
Centralized management: remote control and management of one or more screens, with functions such as scheduled power on/off, scheduled brightness/volume adjustment, screen preview, remote program release, and local (USB) updates.
Permission organization: 5-level organization system for managing materials, programs, terminals and users. Supports creation of custom users, assignment of permissions by user level, and use of permission templates. Multiple security safeguards: 3-level control system for materials, programs and schedules to prevent release errors, data encryption in storage and transmission to prevent tampering, and no default password. users can activate and set initial password to ensure security.
Resolution: 2160 x 3840 Active Display Area: 1209.6 (H) x 680.4 (V) mm
Pixel Pitch: 0.315 (H) mm x 0.315 (V) mm
E-LED Viewing Angle: 178°(H)/178°(V)
Brightness: 500 cd/m²
Contrast ratio: 1200:1
Color depth: 10 bits (8 bits +
FRC) Response time: 8 ms
Color gamut: 72%
NTSC Reliability: 7 x 24h
Refresh rate: 60 Hz
Opacity: 25%
Display ratio: 9 : 16
IPS Operating system: Android 13
Processor: Cortex-A55, 4-core, main frequency 1.92 GHz
Memory: 4
GB Built-in storage: 32 GB EMMC Video and audio input: HDMI 2.0 (HDCP 2.2) x 1 Video and audio output: Speaker (8Ω 5 W) x 2
Network interface: RJ45 x 1, Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax) x 1, RS232 in x 1, RS232 out x 1 Data transmission interface: USB 2.0 x 1, USB 3.0 x 1, BT 5.4 x 1
Input voltage: 100 to 240 VAC, 50/60 Hz
Standby power consumption: max. 0.5 W
Power consumption: 108 W (typ), 155 W (max) Working environment
Working temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working humidity: 10% to 80% RH (Condensation)
Storage temperature: -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
Storage humidity: 10% to 90% RH (Condensation)
Mounting Type: Floor standing Product Dimensions(W x H x D): 740 (W) mm x 1886 (H) mm x 480 (D) mm(With stand). 727 (W) mm x 1776 (H) mm x 63.8 (D) mm(Without stand) Package dimensions(W x H x D): 840 (W) mm x 1895 (H) mm x 155 (D) mm
Net weight: 46.5kg
Gross weight: 52kg
Package Contents:Digital signage x 1, stand x 1, power cord x 1, remote control x 1, user manual x 1, quick guide x 1, Regulatory compliance and safety information x 1, stand fixed with M8 screw x 6, wrench x 2, foot x 4, energy efficiency label x 1, swivel wheel x 4, wheel fixed with M4 screw x 16, fixed base bracket x 2,fixed base bracket with M4 screw x 4, expansion screw x 2
High-speed solution for simultaneous acquisition and playback of 8 Ultra HD video channels via 100G Ethernet. For total redundancy, it features 2 100G Ethernet QSFP ports.
UHD+ 2 x 1 HDMI processor designed for advanced scaling, rotation and warping of 4K sources, ultra-low latency, PiP flexibility, full control via OSD, RS-232, Telnet and PC software
