Showtec Colourburst PRO

Technical specifications

Source

• Type of light source LED
• Number of light sources 5
• Power of light source 40 W
• LED color RGBW
• Refresh rate Hz
• Brightness at 2 m 6610 lx

Optics

• Beam angle circular 2 °

Control and programming

• Control mode Built-in program, DMX, Manual, Master/Slave, Sound
• DMX channels 4, 7, 15, 23
• DMX protocols
• OLED display

Movement

• Continuous rotation
• Rotating optics

Electrical connections and characteristics

• Power supply 100-240 V AC 50/60 Hz
• Power consumption 154 W
• Power input connection
• Power Pro Blue Power connector Output
• Power Pro Grey DMX connection XLR 3P In/Out

Mechanical characteristics

• Height (mm) 400 mm (15.748″)
• Width (mm) 322 mm (12.677″)
• Depth (mm) 303 mm (11.929″)
• Weight 5 kg (11.023 lb)
• IP rating (indoor use only)
• Housing, Plastic
• Color Black

Product features

• Active cooling

Rigging

• Mounting options Floor, Quick lock
• Safety attachments Yes

Thermal characteristics

• Maximum ambient temperature 40 °C (104 °F)

Product Compliance

• Energy class T/B/D

Parts included

• Cables included Power Pro cable
• Fixings included Quick lock bracket
