EUROLITE LED Theatre COB 100 WW

• With a beam angle of 40°
• Very high color rendering index (CRI)
• With double bracket
• 4 Digit 7-segment LED display

Mains input and output for power linking up to 8 units For application areas such as: Stage; wedding/gala/events; Trade fair and shop fitting; restaurants, bars and hotels; theater; video and photography; advertisement/Shop window

• Very quiet working noise
• Application possibility: Standing; suspended; on stand
• Scope of delivery
• 1 X spotlight
• 1 X power cord
• 1 X user manual

• Power supply: 100-240 V AC, 50/60 Hz
• Power consumption: 85 W
• IP classification: IP20
• Protection class: Protection class I
• Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug included
• Power output: P-Con (gray), mounting version
• Fuse: T 1 A fuse replaceable
• Lamp type: LED lamp
• LED type: 1 X 100 W COB (chip-on-board) warm white (WW)
• Flash rate: 0.5 - 23 Hz
• DMX channels: 1; 4
• DMX input: 3-Pin XLR (M) mounting version
• DMX output: 3-Pin XLR (F) mounting version
• Cooling: Cooling fan
• Control: Stand-alone; DMX; sound to light via microphone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
• Preprogrammed in: Light´J; Light Captain; Colorchief
• Projection: Flicker-free
• PWM frequency: 21800 Hz
• Beam angle: 40°
• Beam angle (1/2 peak): 40°
• Beam angle (1/10 peak): 70°
• Color temperature: 3100K
• Color rendering index (CRI): 96 Ra
• Illuminance in Lux (lx): Warm white (WW) 1 m: 5692 lx, 3 m: 680 lx, 6 m: 180 lx
• Housing color: Black matte
• Attachment system: Double bracket
• Display type: 4 Digit 7-segment LED display
• Material: Plastic; metal
• Dimensions: Width: 24.3 cm, Depth: 31.1 cm, Height: 32 cm
• Weight: 2.75 kg
• Noise classification: Class 1 (very slight noise, suitable for noise-sensitive environments)
• Photobiological safety: Risk Group 0
• Cable construction: 3 X 1.0 mm² H05VV-F
• Diameter mounting holes: 1 X Ø11 mm
• Material: Metal, 2.5 mm
• Material: Metal, 0.8 mm
• Special product: Not designed for household room illumination
• Intended use: Show effect lighting
