Yes Tech P3.9 MG15 LED Walls Outdoor
  • New

Yes Tech P3.9 MG15


€837.00
Tax included

Quarter display outdoor, IC ICN2065, SMD1515, black shell LEDs, 5500 - 6000 nit, max. 7680 Hz, 250 x 500 mm, 4.2 kg


Out of Stock

Free shipping


wishlist

Yes Tech P3.9 MG15



Right-angle shaped LED display (P3.9 MG15), 3.9 mm pixel pitch, SMD1515, black shell LED, ICN2065, for outdoor use (5500 - 6000 nits).

It is part of the MG Creative Extension series which includes triangle, rectangle, circular sector etc. This newly updated series will allow you to think and design the stage even more creatively, not only with the arc layout and presentation, but also polygon, sector, etc.

By combining the Magic Stage LED wall modules with the MG Creative Extension, which includes right angle (MG11), triangle (MG12), circular sector (MG13) etc. LED displays, you can realize a variety of creative displays of the desired shape, such as numbers, letters, columns, Christmas tree, diamond, windmill, flower, heart, etc.

  • User benefits
  • Allows you to create LED walls of different shapes by combining the cabinets of the Magic Stage series
  • Areas of use
  • All those in which the Yes Tech LED displays of the Rental and Staging series are used
  • Cabinet Cabinet size: 250 x 500 x 73 mm
  • Cabinet area: 0.125 m 2
  • Weight: 4.2 kg/cabinet Pixel density 65,536 dot/m 2 IP grade IP65
  • White balance brightness before calibration: 5500 - 6000 nit
  • Color temperature: 6500 - 10,000 K adjustable Horizontal viewing angle 160°
  • Vertical viewing angle: 120°

Electrical parameter

  • S Power consumption: 650 / 220 W/m 2
  • Working voltage: 100 - 264 V AC 50/60 Hz
  • Processing performance Driving method constant drive Scanning method: 1/8 s Driving IC ICN2065
  • Refresh frequency: max. 3840 Hz

YES-P3.9MG15O21

Data sheet

Miscellaneous
Suitable for outdoor use
Pixel Pitch
3.9 mm
Giorni di elaborazione
3
