Showtec Shark Wash Zoom Two

Specifications

Source

• Light Source Type
• LED
• Light Source Type Spot
• LED
• Light Source Quantity
• 7
• Light Source Power
• 30 W
• LED Colour Type
• RGBW
• Lux @ 2m
• 36055 lx
• Lux @ 3m
• 16025 lx
• Lux @ 5m
• 5769 lx
• Lumen Total
• 2065 lm
• Lumen Red
• 467 lm
• Lumen Green
• 896 lm
• Lumen Blue
• 232 lm
• Lumen White
• 1117 lm

Optical

• Beam Angle Circular (min)
• 6°
• Beam Angle Circular (max)
• 38°
• Zoom Type
• Motorised
• Zoom Minimum
• 6°
• Zoom Maximum
• 38°

Control and Programming

• Control Mode
• Built-in Program, DMX, Master Slave, Remote, Sound
• DMX Channels
• 8, 15
• Protocols
• DMX
• Display
• OLED

Dynamic Effects

• Dimmer
• 0-100 %
• Strobe
• 0-25 Hz

Movement

• Pan
• 540°
• Tilt
• 210°
• Continuous Movement
• No

Electrical Specifications and Connections

• Power Supply
• 100-240 VAC 50-60 Hz
• Power Consumption
• 220 W
• Fuse
• 5 A
• Power Connector in
• Power Pro Blue
• Power Connector out
• Power Pro Grey
• DMX Connector
• XLR 3P In/Out
• DMX Connector in
• XLR 3P
• DMX Connector out
• XLR 3P

Mechanical Specifications

• Length (mm)
• 246 mm
• Width (mm)
• 154 mm
• Height (mm)
• 355 mm
• Weight
• 5.55 kg
• IP Rating
• IP20 (indoor use only)
• Housing
• Plastic
• Colour
• Black

Product Properties

• Cooling
• Axial fan

Rigging

• Safety Eyes
• 1

Thermal Specifications

• Maximum Ambient Temperature
• 40 °C
• Maximum Surface Temperature
• 70 °C
• Minimum Operating Temperature
• -5 °C

Included Items

• Included Cables
• Power Pro Cable
• Included Rigging
• Bracket
