Omnitronic PAS-212 MK4 2-way Top

• Trapezoidal, multi-functional multiplex cabinet with scratch-resistant lacquer surface
• Optimized for combination with PAS subwoofers
• Dual flange
• With rigging points
• Black metal grille with acoustic foam
• Rugged carrying handle
• Application possibility: Standing; suspended; monitoring; on stand
• For application areas such as: Clubs/dancing school; installation; mobile use; mobile djs / entertainer; restaurants, bars and hotels; rental

Scope of delivery

• 1 x compact cabinet speaker
• 1 x user manual

• Power: Program: 600W, Rated: 300W RMS
• Frequency range: 60 - 20000 Hz
• Sensitivity: 95 dB (1W/1m)
• Max. SPL: 123 dB
• Dispersion angle: 90° x 60°
• Impedance: 8 ohms
• Attachment system: Dual flange: Ø 35mm (0° / 5°)
• Flying points: 12 x M8 thread; 4 x M10 thread
• Connections: Input: speaker via 2 x speaker built-in socket (F)
• Crossover frequency: 2700 Hz
• Speaker: 1 x woofer 12 with ferrit magnet, Basket material: steel, Conematerial: cardboard/paper, Voice coil lows 3, 1 x compression tweeter highs 1 with ferrit magnet, Voice coil compression tweeter highs 1.75
• Type of speaker: Compact cabinet speaker
• Type of construction: Vented
• Carrying handle: 1 pc/pcs
• Material: Plywood multi-layer glued, 15 mm
• Color: Black, painted
• Dimensions: Width: 36.5 cm, Depth: 59 cm, Height: 38 cm
• Weight: 18.80 kg
