Wolfmix W1 MK2


€819.00
€782.00 -4%
Tax included
Lowest price within the last 30 days: €782.00

Standalone-DMX-Performance-Controller


Qty
Immediate availability
Free shipping

wishlist

100% secure payments

Wolfmix W1 MK2







Wolfmix W1 is a standalone performance DMX lighting controller - designed for creating light shows on the fly without a computer.

A toolbox of FX modules, music sync, and up to 4 DMX universes - packed inside robust hardware with a powerful processor. Choose from 1000’s of light fixtures, or build your own directly inside the controller. Whether it’s for a live performance, disco, club or show - Wolfmix has you covered.

Hands-on standalone control of your DMX lights

Wolfmix has been designed with the performer in mind, with 37 colored silicone buttons and a 4.3” touchscreen giving direct access to the most important FX and features.

Up to 4 DMX universes right out of the box

Dedicated CPU

Robust beam engine, coded low-level straight onto the silicon, unlocking the raw power of the WOLFs 220 million heartbeats per second.

Flash memory

16MB of lighting fast readable NOR flash memory ensures the Wolfmix never misses a beat, with changes written on-the-fly.

Strong construction

Powder-coated steel base with VESA mount, and reinforced steel back-plate armour the WOLF for tough conditions.

High End finishing

A laser printed matt oil finish for durable, yet soft-to-touch silicon pads, backlit with color changing LEDs.

Touch screen

4.3” capacitive touch display with tinted glass. Fine-tune your project with the color picker, pan/tilt grid and on-screen keyboard for naming presets.

Push encoders

4 incremental push encoders with acceleration, for fine-tuning parameters whilst flying from 0-100% with a single twist.

The Wolfmix toolbox

WTOOLS app for PC & Mac computers

Wolfmix operates as a standalone controller without any computer required. Wolfmix can also be connected to a computer's USB3 socket for some additional functionality with the WTOOLS app.

Cloud project backup

Backup your projects onto a computer. Backups are automatically synchronized via the cloud and can be downloaded onto any Wolfmix, anywhere.

Beat sync with DJ software

Take the BPM calculated by your music production and DJ software using Ableton Link or OS2L. WTOOLS will read the beat and pass it to the Wolfmix.

15000+ fixture profiles

Never be stuck without a profile. Backup fixture profiles created on the Wolfmix, or load any profile from the Nicolaudie SSL2 fixture library.

3D visualizer

Create a 3D representation of your stage, and render your project in real-time with Easy View 2 without any DMX input interface required (add-on purchase required).

Pair up a second Wolf

..or a DMX IN controller with WLINK

Connect 2 Wolfmix controllers together with the 5pin-5pin WLINK cable (available separately) and both will follow each other. This allows for up to 8 groups to be controlled side-by side, or for dual control by extending with a standard 5pin DMX cable. Sync a Wolfmix behind the bar with another in the DJ booth, or a Wolfmix on stage with another Front Of House.

Alternatively, the WLINK socket can be used to connect a DMX controller such as a traditional DMX faderboard- allowing for DMX input channels to be mapped to group dimmers or directly to output channels. WLINK requires an add-on purchase available through the WTOOLS app.

Hardware

Size & weight

  • 195 x 220 x 62 mm / 7.68 x 8.66 x 2.44 in
  • 1070g / 2.36lb

Components

Housing

  • ABS Plastic
  • Powder-coated steel base plate with 100mm VESA (M4 6mm max)
  • Powder-coated steel reinforced back plate

Display

  • 4.3” Color TFT with tinted glass
  • Capacitive touch

Encoders

  • Alloy encoder caps
  • Incremental push with acceleration

Button pads

  • 37 Silicone buttons with matt oil finishing
  • LED color backlit

Processing

  • 220Mhz CPU with ARM core
  • 8MB RAM
  • 16MB Flash

Audio

  • Omnidirectional electret mic
  • 3.5mm Jack Line-In
  • Analog adaptive peak detector

DMX

  • 2x 3pin DMX OUT XLR connectors
  • 1x 5pin DMX OUT XLR connector
  • 1x 5pin DMX IN/OUT XLR connector with WLINK

USB

  • USB-B connector- 900ma required (USB3 rating)
  • USB-A connector (MIDI/MSD)

Features

Setup

  • Standalone (no computer needed)
  • Compatible with any DMX device
  • Up to 4 DMX universes (2048 channels. Add-on required for U3+4)*
  • Up to 680 fixtures & beams
  • Up to 50 fixture types
  • Up to 5000 fixture features (color/gobo etc...)
  • 8 fixture groups
  • 6 projects
  • 15000+ available fixtures (3500+ on the controller)
  • DMX address, fixture order & group setup
  • Use as a DMX splitter with DMX universe mapping
  • Backup and restore projects and fixtures from a USB memory stick

Palettes & FX

  • Color FX module with 8 effect types & 16 definable colors
  • Move FX module with 8 effect types
  • Beam FX module with 8 effect types
  • 6 Flash buttons for controlling Special FX, Strobe, Blinder, Speed, Blackout & Smoke
  • Static color palette with 10 user definable colors per group & gradient control
  • Static position palette with 5 user definable positions per group with fade & fanning
  • Gobo palette with 5 user definable gobos per group
  • 40 namable live edit buttons with flash triggering mode and ‘Park’ function
  • 100 namable presets for storing snapshots with hold and fade timings
  • Preset playback cue list- all presets or per page of 20 presets

Control & Sync

  • Group and master dimming with encoder acceleration
  • Group FLASH, FULL and Blackout
  • 16 bit Pan/Tilt control
  • Multi-beam LED bar control
  • FX music pulse sync from Microphone or Line-In
  • FX BPM sync with Ableton Link, OS2L, BPM TAP & MIDI Clock
  • Effect Speed, Phase, Order, Size, Fade, Fan & Flick
  • Live control of move FX registration point
  • Global FX speed and freeze control
  • Map DMX IN with group dimmer and patch to output channels (add-on required)*
  • WLINK - sync with another Wolfmix controller (add-on required)*
  • Trigger presets and control group dimmers with a MIDI controller

Built-in tools

  • Fixture Builder
  • Fixture calibration tool, to limit the area of moving fixtures
  • X-Y touch controlled positioning grid
  • RGBW touch controlled color picker
  • 8-step real time sequencer for creating beam and move FX
  • Live view of DMX levels with default value override and DMX channel tester
  • Beam Editor to override Min and Max values used in generated FX

Other neat features

  • Calibrate and RGB, White, Amber, UV mixing with automatic fixed color wheel translation
  • Timed release of flash and preset buttons
  • Fixture FLIP function, for reversing beam order
  • Fixture SPLIT function, for splitting up multi-FX bars
  • Lock full controller, or lock editing with a password
  • Project & fixture backup with WTOOLS app
  • Offline 3D visualization with Easy View & WTOOLS over USB (add-on required)*
  • Auto-recovery of active project (no manual saving needed)
  • Import different fixture setups into the same project
  • Starts in under 2 seconds. Starts sending DMX in under 1 second
  • Factory firmware startup recovery mode for times of crisis
