PSSO KX-P212A 2-way Speaker, active, DSP

• Active PA speaker system for touring applications and permanent installations
• Versatile setup options with the KX subwoofer and specially tuned presets
• High-quality and sturdy PP cabinet with internal bracing, qualified for suspension
• DSP-controlled biamp amplifier (class D)
• 2-way bass-reflex system
• Line input (XLR/6.3 mm jack) with separate level control
• Mic/line input (XLR/6.3 mm jack) with separate level control
• Mixed output for linking further active speaker systems
• Digital signal processor FIR Filter
• DSP presets: LIVE; MONITOR; MUSIC; SPEECH; SUB; FLAT
• The device is cooled by passive convection cooling
• With rigging points
• Black metal grille with acoustic foam
• 3 Rugged carrying handles

Scope of delivery

• 1 x top
• 1 x power cord
• 1 x user manual

• Power supply: 230 V AC, 50 Hz
• Power consumption: 1000 W
• IP classification: IP20
• Protection class: Protection class I
• Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
• Power output: 1 x P-Con (gray), mounting version
• Power: 700W RMS, Peak: 1400W
• Frequency range: 56 - 20000 Hz
• Max. SPL: 135 dB
• DSP: Digital signal processor FIR Filter
• DSP presets: LIVE; MONITOR; MUSIC; SPEECH; SUB; FLAT
• Dispersion angle: 90° x 60°
• Cooling: Passive convection cooling
• Attachment system: Flange:
• Flying points: 3 x M10 thread
• Circuitry: Class D Biamp
• Control elements: Power switch, groundlift selector, Input sensitivity switch, DSP preset switch, level control per channel
• Controls: Overheat; DC voltage; short-circuit; limiter
• Status LED: Power, signal, clip
• Connections: Input: mic/line via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version), Input: line via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version), Output: line via 1 x 3-pin XLR (M) mounting version
• Speaker: 1 x woofer 12 with ferrit magnet, Basket material: steel, Conematerial: cardboard/paper, Voice coil lows 3, 1 x compression tweeter highs 1 with ferrit magnet, Voice coil compression tweeter highs 1,5
• Type of speaker: Compact cabinet speaker
• Type of construction: Vented
• Carrying handle: 3 pc/pcs
• Material: PP polypropylene, powder-coated
• Color: Black, matte
• Dimensions: Width: 35 cm, Depth: 33.5 cm, Height: 63 cm
• Weight: 17.75 kg
• Cable construction: 3 x 0.75 mm² H05VV-F
• Cable length: 2.5 m detachable
