PSSO DCA-12000 2-channel SMPS Amplifier

PSSO
€2,072.00
€1,553.00 -25%
Tax included
Lowest price within the last 30 days: €1,553.00

Class I stereo PA amplifier with SMPS, 2 x max. 6000 W (2 ohms), 2 x max. 3900 W (4 ohms)

Qty

In Stock

Delivery

Do You want Your order by Wednesday, 24/06/2026? Order within 4 hours and 16 minutes

Free shipping

Compare

wishlist

PSSO DCA-12000 2-channel SMPS Amplifier



  • Low weight and height due to integrated switch mode power supply
  • Reliable power amp with high impulse stability for a wide range of applications (e.g. compact PAs, multi-way PAs, concerts)
  • Limiter and speaker switch-on delay
  • 3 operating modes can be selected (stereo, parallel or bridged)
  • Level control per channel
  • Input sensitivity adjustable
  • LED VU meter and LEDs for activated protective circuit (protect) and overload (clip) per channel
  • Electronically balanced inputs via XLR mounting jacks, with XLR feed-through outputs
  • Speaker outputs via lockable Speaker plugs
  • Rugged steel chassis with aluminum front panel
  • (19) 48.3 cm rack installation 2 U
  • Highly efficient air flow from front to rear
  • The device is cooled by temperature-controlled fan
  • Built with NEUTRIK connector
  • For application areas such as: Stage; concerts/FoH's; rental; mobile djs / entertainer; restaurants, bars and hotels; sports centres/gyms

Scope of delivery

  • 1 x amplifier
  • 1 x cover
  • 4 x foot
  • 1 x user manual
  • Power supply: 230 V AC, 50 Hz
  • Power consumption: 1050 W 1/8 power
  • Protection class: Protection class I
  • Output power: 2 x max. 6000 W (2 ohms), 2 x max. 3900 W (4 ohms), 2 x max. 2300 W (8 ohms), 1 x max. 10000 W bridged (4 ohms), 1 x max. 6200 W bridged (8 ohms)
  • Power connection: Fixed power supply cord with safety plug
  • Cable length: 1.6 m
  • Frequency range: 20 - 20000 Hz
  • S/N ratio: 90 dB
  • THD: 0.05 % at 1 kHz
  • Cooling: 3 x temperature-controlled fan , air flow from front to rear
  • Impedance: Input: 10 kOhm , unbal., Input: 20 kOhm , bal.
  • Gain: 38 dB/ 0.775 V, 32 dB/ 1.0 V, 26 dB/ 1.4 V
  • Housing color: Black
  • Circuitry: Class I
  • Slew rate: 10 V/µs
  • Damping factor: 200
  • Control elements: Power switch, level control per channel, mode switch (stereo/parallel/bridged), Input sensitivity switch, limiter selector
  • Controls: Overheat; overload; short-circuit; softstart; DC voltage; VHF; limiter
  • Status LED: Power, level meter, clip, protect
  • Connections: Input: line via 2 x 3-pin XLR (F) mounting version, Output: line via 2 x 3-pin XLR (M) mounting version, Output: speaker via 2 x speaker built-in socket (F)
  • Input sensitivity: 0.775 V; 1.0 V; 1.4 V , switchable; 26 dB; 32 dB; 38 dB , switchable
  • Use of brands: Built with NEUTRIK connector
  • Material: Steel
  • Housing design: (19) 48.3 cm rack installation 2 U
  • Dimensions: Width: 48.3 cm, Depth: 44.0 cm, Height: 8.9 cm
  • Weight: 14.20 kg

PSSO
10451693

Data sheet

Channels
2 channels
