• New

Definitive Audio QUAD 150D


€590.00
Tax included

4 X 150 W RMS amplifier at 4 ohm


Out of Stock

Free shipping


wishlist

Definitive Audio QUAD 150D



Definitive Audio is proud to present its new range of 4-channel amps: the QUAD series! Ideal for audio professionals who expect high performance and reliability from their products, this range is bursting with excellent design features, high audio quality, connections and a highly comprehensive range of settings. The range consists of 3 models, specifically adapted to all types of use depending on the power required - ranging from 4 x 75 Ws to 4 x 300 Ws. The QUAD 75, QUAD 150 and QUAD 300 operate at 8 and 4 ohm, and also at 2 ohm in bridged mode, for a variety of applications. They are traditionally made with a 2U height and in 19 rack format, and they can be easily placed in a flight case or a control room.

Technical specifications

  • Continuous power at 0.5% THD: 4 ohms (4 x 150 W), 8 ohms (4 x 110 W)
  • ELAJ power at 1% THD: 4 ohms (4 x 200 W), 8 ohms (4 x 120 W)
  • Bridged mode: 8 ohms (2 x 600 W)
  • Input sensitivity: 1.414 VRMS
  • Input impedance: 10 kohms unbalanced, 20 kohms balanced
  • Frequency responce: 20 Hz - 20 kHz +-0.1 dB, -3 dB points: 10 Hz - 60 kHz
  • Input clipping: 8 VRMS (+20 dB)
  • Voltage gain: 32 dB
  • Distorsion (SMPTE- IM): 0.5%
  • S/N ratio: 105 dB
  • Connectors: input (balanced XLR and jack), output (jacks)
  • Front control: power switch, gain knobs
  • Rear control: mode switch
  • Power supply: 230 V∿, 50/60 Hz
  • Dimensions: 530 x 420 x 88.9 mm
  • Weight: 8.70 kg

SOG-2200_QUAD_150D

Specific References
