PSSO DDA-2700 MK2 2-channel Amplifier Amplifiers
  • -24%

PSSO DDA-2700 MK2 2-channel Amplifier

PSSO
€669.00
€507.00 -24%
Tax included
Lowest price within the last 30 days: €507.00

Class TD stereo PA amplifier with SMPS, 2 x 1350 W RMS (4 ohms), 2 x 1000 W RMS (8 ohms)

Qty

In Stock

Delivery

Do You want Your order by Thursday, 25/06/2026? Order within 2 hours and 22 minutes

Free shipping

Compare

wishlist

PSSO DDA-2700 MK2 2-channel Amplifier



  • Low weight and height due to integrated switch mode power supply
  • Reliable power amp with high impulse stability for a wide range of applications (e.g. compact PAs, multi-way PAs, concerts)
  • Limiter and speaker switch-on delay
  • 3 operating modes can be selected (stereo, parallel or bridged)
  • 2 calibrated level controls for precise level adjustment
  • Input sensitivity adjustable
  • LED VU meter and LEDs for activated protective circuit (protect) and overload (clip) per channel
  • Electronically balanced inputs via XLR mounting jacks, with XLR feed-through outputs
  • Speaker outputs via lockable speaker jacks and pairs of screw terminals
  • Rugged steel chassis with aluminum front panel
  • (19) 48.3 cm rack installation 2 U
  • Highly efficient air flow from front to rear
  • The device is cooled by temperature-controlled fan

Scope of delivery

  • 1 x amplifier
  • 1 x power cord
  • 4 x foot
  • 1 x user manual
  • Power supply: 100-240 V AC, 50/60 Hz
  • Power consumption: 740 W 1/8 power
  • IP classification: IP20
  • Protection class: Protection class I
  • Output power: 2 x 1350 W RMS (4 ohms), 2 x 1000 W RMS (8 ohms), 1 x 2600 W RMS bridged (8 ohms)
  • Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug included
  • Cable construction: 3 x 1 mm² H05VV-F
  • Frequency range: 20 - 20000 Hz +-
  • S/N ratio: 100 dB
  • THD: 0.05 % at 1 kHz
  • Cooling: 2 x temperature-controlled fan , air flow from front to rear
  • Gain: 32 dB, 36 dB, 41 dB
  • Housing color: Black matte
  • Circuitry: Class TD
  • Slew rate: 15 V/µs
  • Damping factor: 400
  • Crosstalk: 70 dB
  • Control elements: Power switch, level control per channel, Input sensitivity switch, mode switch (stereo/parallel/bridged)
  • Controls: DC voltage; short-circuit; limiter; softstart; overheat; VHF; overload
  • Status LED: Power, signal, level meter, clip, protect; bridged
  • Connections: Input: line via 2 x 3-pin XLR (F) mounting version, Output: line via 2 x 3-pin XLR (M) mounting version, Output: speaker via 2 x speaker built-in socket (F), Output: speaker via screw terminal
  • Input sensitivity: 0.775 V; 1.4 V; 2.2 V , switchable
  • Max. level: Input: +20 dBu, Input: +9 V
  • Housing design: (19) 48.3 cm rack installation 2 U
  • Mounting depth: 33.8 cm
  • Dimensions: Width: 48.3 cm, Depth: 34.0 cm, Height: 8.9 cm
  • Weight: 6.80 kg
  • Weight: 6.8 kg
  • Weight: 0.26 kg
