Dimmer electronic; color selection adjustable; program selection manual; Energy-saving mode adjustable; program speed adjustable; Rotation speed adjustable; Rotation direction adjustable
Multi beam effect; laser; strobe effect
Laser class 2M does not require additional protective measures or appointment of a laser safety officer
7 integrated show programs
Highly efficient air flow from front to rear
The device is cooled by low-noise cooling fan at the base
Control via stand-alone; DMX; AirW; sound to light via microphone; master/slave function; wireless remote control; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Flicker-free
DMX fail mode (blackout; hold; auto; full on)
With omega bracket
Monochrome 4 digit 7-segment LED display
Charge status indicator
Mains input and output for power linking up to 8 units
For application areas such as: Clubs/dancing school; wedding/gala/events; mobile djs / entertainer; party room; restaurants, bars and hotels; advertisement/Shop window
Very quiet working noise
Application possibility: Standing; suspended
3 buttons on the remote control for saving your own settings
remote control
Operating range up to 50m in the open air
Scope of delivery
1 x light effect
1 x power cord
1 x omega bracket
1 x user manual
1 x remote control
4 x screw
4 x washer
1 x declaration of conformity
1 x battery
Power supply: 100-240 V AC, 50/60 Hz
IP classification: IP20
Protection class: Protection class I
Power connection: Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided), Battery/battery pack built-in
Cable construction: 3 x 1.0 mm² H05VV-F
Power output: 1 x IEC connector (F) mounting version Bypass
Device fuse: 5 x 20 mm, T 2 A fuse replaceable
Battery pack type: 1 x lithium ion 18.5 V, 13000 mAh, 240.5 Wh
Battery pack: Battery operation up to 11h depending on program used, Recharging time 7h
LED type: 5 x 8 W SMD 9095 4in1 QCL RGBW
Flash rate: 1 - 20 Hz
Laser class: 2M
Laser color: R/G
Laser module: Red 100 mW 650nm, Green (G) 40 mW 532nm
DMX channels: 3; 10; 22
DMX input: 1 x 3-pin XLR (M) mounting version
DMX output: 1 x 3-pin XLR (F) mounting version Bypass
Cooling: 1 x low-noise cooling fan at the base, air flow from front to rear
Control: Stand-alone; DMX; AirW; sound to light via microphone; master/slave function; wireless remote control; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Projection: Flicker-free
DMX fail mode: Blackout; hold; auto; full on
Housing color: White
Attachment system: Omega bracket
Display type: Monochrome 4 digit 7-segment LED display
Display: Charge status indicator
Status LED: Power, charge status indicator
USB port: 1 x type A
Material: Metal, painted
Dimensions: Length: 32 cm, Width: 26 cm, Height: 39 cm
Weight: 7.00 kg
Noise classification: Class 1 (very slight noise, suitable for noise-sensitive environments)
Material thickness: 3 mm
Battery: 1 x 12 V 23AE alkaline manganese built-in
