Harmonic Design IC230


€408.00
Tax included

40 W ceiling mount speaker, 2 ways, vented design, 3,5 coax, 80° x 80°, 8 ohm and 70 / 100 V, 99 mm installation depth


Out of Stock

Free shipping


wishlist

Harmonic Design IC230



Hd IC230 is a compact ceiling speaker designed to deliver excellent speech intelligibility and superior sound quality.

Despite its reduced installation depth of just 99 mm, this coaxial two-way passive speaker provides an extended frequency response, also ideal for background music. Its versatility is ensured by the ability to operate in both 8 ohm low impedance systems and 70 / 100 V configurations, thanks to a five-position switch that allows it to be easily adapted to any application.

Installation is quick and easy thanks to the quick-release fixing clips and the included template, while the paintable front grille allows for perfect integration into any environment.

Equipped with a 3.5 and #34; mid-woofer and a 1 and #34; coaxial tweeter, the hd IC230 delivers crystal-clear highs and rich mids, ensuring a powerful and balanced sound: an ideal solution for professional installations that require high performance and elegant aesthetics.

  • User benefits
  • Sound quality
  • Flexibility (both low impedance and 70 / 100 V operation)
  • Easy assembly
  • Discreet and integrable design
  • Fits into spaces with structural constraints thanks to the reduced installation depth of only 99 mm
  • Areas of use
  • Hotels
  • Restaurants
  • Conference rooms
  • Shops

Technical characteristics

  • Acoustic design: coaxial
  • Transducers: 3.5 woofer + 1 tweeter
  • Frequency response: 70 Hz - 22 kHz
  • Crossover frequency: 4 kHz
  • Power rating: 40 W (RMS), 55 W (peak)
  • Impedance (low Z): 8 ohm

Transformer (High Z)

  • Sensitivity: 88 dB/W/m
  • SPL max.: 111 dB
  • Nominal beam angle: conical 80°
  • Termination: standard installation terminals
  • Enclosure: white powder-coated fire pot with removable steel grille

Terminal block

  • Ceiling cutout: Ø 20.6 cm
  • Outer dimension: Ø 23 cm
  • Max. installation depth: 9.9 cm
  • Dimensions (Ø x H): 23 x 10.6 cm
  • Weight: 2 kg

HDE-40191
