Multiple interfaces: HDMI, VGA, USB. - Built-in speakers 2 x 5 W. - Low blue light for eye protection. - Built-in 3D noise reduction. - Compatible with VESA wall mount.
DISPLAY Screen Size: 43
Active Area: 950.896 mm x 529.254 mm
Resolution: 1920 x 1080 at 60 Hz
D-LED Pitch Pixels: 0.49005 mm x 0.49005 mm
Brightness: 300 cd/m²
Viewing Angle: 178° / 178°
Color Depth: 8 bit
Contrast Ratio: 4000 : 1
Response Time: 6.5 ms (typ)
Refresh Rate: 60 Hz
Haze: 25
Color Gamut: 72
NTSC Reliability: 7 x 24 H INTERFACES Video Input and
Audio: VGA x 1, HDMI 1.4 x 1 Video Output and
Audio: Line Out x 1, Speaker Out x 2 (8 Ω 10 W)
Data Interface: USB 2.0 x 1
POWER SUPPLY Power supply: 100 - 240 VAC, 50/60 Hz, 1.0 A max
Power consumption: max. 80 W
Stand-by: 0.5 W max
Operating Humidity: 20% - 90% RH (non-condensing)
Storage Temperature: -20 °C / 60 °C (14 °F / 140 °F)
Storage Humidity: 5 % - 90 % RH (non-condensing)
GENERAL Speakers: 8 Ω 10 W x 2
Plastic VESA: 7.87 x 7.87
Bezel Width: 0.04 (top/left/right), 0.94 (bottom) Dimensions (without base): 37.57 x 22.11 x 2.99 Dimensions (with base): 37.57 x 24.26 x 9.53
Packaging Dimensions: 1073 x 668 x 161 mm (42.24 x 26.30 x 6.34)
Net Weight: 6.85 +- 0.5 kg
Gross Weight: 9.98 +- 0.5 kg PACKAGE CONTENT Monitor x 1, Base components x 1 Power cord x 1 HDMI cable 1.5 m x 1 User's manual x 1, Multilingual manual x 1 Remote control x 1, Screws x 6 *Base is included as standard. *Appearance and parameters may vary from the actual device. please contact your local sales staff for more information.
