Hikvision Ledwall Controller 1U 20-Port 2-in-1DATA OUT LED Wall Management
  • New

Hikvision Ledwall Controller 1U 20-Port 2-in-1DATA OUT

€2,466.00
Tax included

1U 20-Port 2-in-1DATA OUT Ledwall Controller

Out of Stock

Free shipping

Compare

wishlist

Hikvision Ledwall Controller 1U 20-Port 2-in-1DATA OUT



  • OF ELABORATION Brightness control: Adjustable from 1 to 100 (white balance level by level)
  • Frame rate: 25 Hz to 60 Hz
  • Gray level: 256
  • Displayed colors: 16
  • MP Processing depth: 8 bits
  • Chassis width: 440 mm (17.32 inch)
  • LED controller Average consumption: max. 43 W Number of power interfaces: 1 Power interface specifications: 100 - 240 VAC, 50/60 Hz
  • VIDEO WALL Open windows: 3 signal source windows + 2 image windows + 1 scrolling text window + 1 background window
  • Levels per device: 7
  • Scenes: 10
  • Background images: 1
  • Min.: 640 x 480,
  • Max: 1920 x 1200
  • JPG/JPEG Subtitles: 1
  • Subtitle width: 32760
  • Subtitle font: Supports Xiaomi fonts and custom fonts
  • Net weight: 3.30 kg (7.28 lb.)
  • Gross weight: 4.50 kg (9.92 lb.) Dimensions (W x H x D): 440 mm x 44.5 mm x 320.8 mm (17.32 inch x 1.75 inch x 12.63 inch) PACKAGE CONTENT 1 x AC power cord 1 pair of mounting brackets 2 x green Phoenix RS-485 connectors for central control devices 1 x compliance and safety manual 1 pair of rubber feet
  • AUDIO INPUT Number of interfaces: 2
  • Interfaces type: 1 HDMI channel with built-in audio + 1 HDMI channel with in-band audio
  • VIDEO INPUT Number of interfaces: 3
  • Interfaces type: 1 HDMI2.0 + 1 HDMI1.4 + 1 DVI Maximum video input resolution: HDMI 2.0: 4K. HDMI 1.4 and
  • DVI: 1080p HDMI 2.0 Resolutions
  • Max: 4096 x 2160 at 60 Hz
  • Min: 320 x 180 at 60 Hz Custom resolution supported, max 8.84
  • Height: 144~8192 (alignment: 1) Supports HDCP 2.2 Interlaced signals not supported HDMI 1.4 /
  • DVI Max: 1920 x 1200 at 60 Hz
  • Min: 320 x 180 at 60 Hz Custom resolution supported, max 2.6
  • Height: 144~4096 (alignment: 1) Supports HDCP 1.4 Interlaced signals not supported Video processing features
  • Depth: 8 bit
  • RGB: 444
  • YUV: 444, 422, 420 VIDEO OUTPUT Number of output interfaces: 12 Maximum video output resolution: 13 million
  • Output type: RJ-45 LED load capacity per output
  • Per port: 650000
  • Width: 144~8192 (alignment: 2)
  • Height: 64~8192 (alignment: 1) Load interfaces
  • LED Number of interfaces: 20 Looped video outputs 2 interfaces 1 HDMI 2.0 + 1 DVI Looped video output resolution HDMI 2.0
  • Max: 4096 x 2160 at 60 Hz
  • Min: 320 x 180 at 60 Hz Output resolution equal to input Supports HDCP 2.2
  • DVI Max: 1920 x 1200 at 60 Hz
  • Min: 320 x 180 at 60 Hz Output resolution equal to input Supports HDCP 1.4
  • LIVE VIEW OUT Number of interfaces: 1
  • Type: HDMI 1.4
  • AUDIO OUT Number of interfaces: 1
  • WIRELESS Remote control: Supports IR remote control and
  • RF FRONT PANEL Display: OLED 128 x 64
  • USB port: 1 x USB 2.0
  • Buttons: + to increase brightness, - to decrease brightness, Source to change source
  • Indicators: Active (device running), Source (source connected), Error
  • Power switch: On (device on), Off (device off/not started) INTERFACE
  • CONTROL PORT Network port: 2 x Ethernet RJ-45 10/100/1000 Mbps self-adaptive Supports multi-device daisy-chaining
  • IR input: 1 x 3.5 mm connector, supports remote control
  • IR Serial interfaces: 1 x debug serial port (4-pin connector) 1 x RS-485 for central control (Phoenix green) 1 x RS-485 for light sensor (Phoenix green)
  • Baud rate: 115200
  • Data bits: 8
  • Power switch: Button

DS-DT60V-03HDI20NO
