Hikvision Ledwall Solid Series - P1.8 Indoor LED Walls Indoor
  • New

Hikvision Ledwall Solid Series - P1.8 Indoor


€358.00
Tax included

Ledwall Solid Series - P1.8 Indoor


Out of Stock

Free shipping


wishlist

Hikvision Ledwall Solid Series - P1.8 Indoor



DS-D4018CW-2F 600*337.5/mm P1.8 INDOOR The display and control system is fully self-developed, ensuring stability, security and control.

Highly integrated and compatible cabinet with simple and lightweight design.

Easy disassembly of LED panel, power supply and receiver board from the front side due to high-precision die-cast aluminum design.

Soldering irons are made of lead-free and non-toxic materials that are safe for the human body and the environment.

Automatic detail identification of high brightness and complex images, with partial area brightness adjustment by dynamic motor algorithms. The image results soft, comfortable to view and superior quality, with reduction of unnecessary power consumption.

Automatic moisture removal to protect the LED panel from water damage, ideal in humid environments or when unused for long periods of time.

  • DS-D4018CW-2F Product Type: Indoor fine pixel color LED display
  • SMD Triad LED Pixel Pitch: 1.875 mm (0.074)
  • Pixel Pitch Category: P1.8
  • Pixel Density: 284,444 dots/㎡
  • Module Composition: 2 x 2 Dimensions (W x H x D): 600 mm x 337.5 mm x 29.5 mm (23.622 x 13.287 x 1.161)
  • Resolution: 320 x 180
  • Area: 0.2025 ㎡
  • Weight: 3.4kg
  • Cabinet Material: Die-cast aluminum
  • Maintenance Method: Front maintenance for all components
  • MODULE Dimensions: 300 mm x 168.75 mm
  • Module Resolution: 160 x 90 DISPLAY
  • Color Temperature: Adjustable from 3000 K to 10000 K
  • Viewing Angle: Horizontal 160°, Vertical 160°
  • Contrast Ratio: 5000:1
  • Color Uniformity: max. +- 0.003
  • Cx,Cy Brightness Uniformity: min. 97% PERFORMANCE
  • PROCESSING Driving Method: Constant Current Driving
  • Number of Scans:45
  • Frame Frequency: 60 Hz
  • Refresh Rate: 3840 Hz
  • Gray Level: 16 bit
  • POWER Consumption Maximum: max. 400 W/㎡ (600nits)
  • Average Consumption: max. 140 W/㎡
  • Input Voltage: 100~240 VAC +- 10% ENVIRONMENT
  • WORKING Temperature: -10℃ to 40℃ (14 ℉ to 104 ℉)
  • Working Humidity: 10% to 60% RH (without condensation)
  • Storage Temperature: -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
  • Storage Humidity: 10% to 85% RH (non-condensing) GENERAL Packing Dimensions (W x H x D): 722 mm x 438 mm x 193 mm (28.425'' x 17.244'' x 7.598'')
  • Packing List: Regulatory compliance and safety information x 1. Various connecting screws, LED chips, driver IC, iron sheets
  • Gross Weight: 4.5 kg (1 package in 1 box)
  • Net Weight: 3.4 kg
  • Modular Stand: DS-DL116033W 1*1. DS-DL126033W 1*2. DS-DL226033W 2*2

DS-D4018CW-2F

Data sheet

Pixel Pitch
1.8 mm
