ROBE MegaPointe


€17,650.00
Tax included

470 W Discharge lamp Beam/Spot Moving Head


Qty
Available upon request
Free shipping

wishlist

ROBE MegaPointe







MEGA bright with MEGA features and still compact. The MegaPointe from Robe.

OUR NEW REFERENCE POINT!

Our all-new MegaPointe elevates the original all-in-one fixture to a whole new level. Unleash your creativity using the bright sharp parallel beams, excellent gobo projection, precise movement, smooth CMY colour mixing and dimming plus a multitude of beam splitting, wash and shaping effects.

The Robe R&D team worked with Osram to provide a 470W lamp that aligns perfectly with the cutting edge optical system. This design provides a brilliant, crystal clear, razor-edged beam, adjustable from a punchy 1.8 out to a wide 42 degree zoom.

Both static and rotating (glass) gobos produce precision in-air effects or projected images with a sharp, high-contrast, flat field.

The newly designed effects engine can produce 12 varying beam and ‘flower’ effects. The beam can also be shaped using innovative shutter emulation, further creating a whole new blend of content & creativity.

Source

  • Lamp: Discharge short arc lamp with integrated reflector
  • Approved model: Osram Sirius HRI 470 W RO
  • Lifetime: 1.500 hours @ 470W Standard mode, 2.000 hours @ 380W Eco mode
  • CRI: 80/90
  • CCT:
  • Light output 6.300K
  • Lamp 7.500K
  • Control: Automatic and remote on/off
  • Ballast: Electronic

Optical system

  • Robe’s proprietary optical design (Patent pending).
  • Zoom optical system: 14:1
  • Light output:
  • Beam mode 1.8°: 2 200.000 lx @ 5 m
  • Beam mode 1.8°: 137.500 lx @ 20m
  • Spot mode 3°: 715.300 lx @ 5 m
  • Spot mode 3°: 44.710 lx @ 20m
  • Zoom range:
  • 1.8° - 21° beam mode
  • 3° - 42° spot mode
  • Output lens diameter: 150 mm
  • Fixture total lumen output: 20.375 lm

Dynamic Effects and Features

  • Cyan: 0 – 100%
  • Magenta: 0 – 100%
  • Yellow: 0 – 100%
  • Colour Wheel: 13 dichroic filters + white
  • Rotating gobo wheel: 9 rotating gobos + open, indexable and replaceable gobos
  • Static gobo wheel: 14 gobos + open
  • Animation wheel: Aluminium animation wheel, used alone or in combination with gobos, rotating in both directions at variable speed
  • Innovative Effect Engine consisting of 6 prisms placed on two wheels, producing 12 various Beam and Flower effects
  • Beam shaper emulating framing shutters and creating rectangular beam shapes, rotatable and indexable (Patented)
  • Frost: variable 1° (light) and 5° (medium)
  • Motorized zoom and focus
  • Remote Hot-spot control: adjustable from 5:1 to 2.5:1 in spot mode and from 7:1 to 2.7:1 in beam mode (Patent pending)
  • Pre-programmed random strobe & pulse effects
  • Dimmer: 0 – 100%

Control and programming

  • Setting & Addressing: ROBE Navigation System 2 (RNS2)
  • Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
  • Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
  • Wireless CRMX™ technology from Lumen Radio - on request
  • DMX Protocol modes: 2
  • Control channels: 39, 34
  • Pan/Tilt resolution: 8 or 16 bit
  • Colour wheel positioning: 8 or 16 bit
  • CMY: 8 bit
  • CRI Selection: 80 or 90
  • Rotating gobo wheel positioning: 8 bit
  • Gobo indexing & rotation: 8 or 16 bit
  • Static gobo wheel positioning: 8 bit
  • Animation wheel: 8 bit
  • Animation wheel rotation: 8 or 16 bit
  • Prism indexing & rotation: 8 bit
  • Frost: 8 bit
  • Zoom: 8 or 16 bit
  • Focus: 8 or 16 bit
  • Hot-Spot: 8 bit
  • Dimmer: 8 or 16 bit

Movement

  • Pan movement: 540°
  • Tilt movement: 265°
  • Movement control: Standard and Speed
  • Automatic Pan/Tilt position correction
  • EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
  • Rotating gobos
  • Glass gobos: 9 rotating gobos + open
  • Outside diameter: 15.9 mm
  • Image diameter: 12.5 mm
  • Thickness: 1.1 mm
  • High temperature borofloat or better glass
  • "SLOT&LOCK" system for easy replacement of gobos

Static gobos

  • Aluminium wheel with fixed gobos: 10 gobos & 4 beam reducers + open position

Thermal specification

  • Maximum ambient temperature: 45 °C
  • Maximum housing temperature: 80 °C
  • Minimum operating temperature: -5 °C
  • Total heat dissipation: max. 1945 BTU/h (calculated)

Electrical specification and connections

  • Power supply: Electronic auto-ranging
  • Input voltage range: 100-240 V, 50/60 Hz
  • Power consumption: 670 W
  • Power in connector: Neutrik powerCON TRUE1
  • DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
  • Ethernet port in: RJ45

Approvals

  • CE Compliant
  • cETLus Compliant

Mechanical specification

  • Height: 640 mm - head in vertical position
  • Width: 396 mm
  • Depth: 230 mm
  • Weight: 22 kg
  • Ingress protection rating: IP20

Rigging

  • Mounting positions: Horizontally or vertically
  • Universal operating position
  • Mounting points: 2 pairs of 1/4-turn locking points
  • 2x Omega adaptors with 1/4-turn quick locks
  • Pan and Tilt transport locks
  • Safety cable attachment point

Included items

  • User Manual
  • Omega Adaptor CL-regular 2 pcs
  • Power cord including powerCON TRUE1 In connector
