Showtec Shark - The Meg - Hybrid One

Specifications

Source

• Light Source Type: LED
• Light Source Quantity: 1
• Light Source Power: 160 W
• LED Colour Type: CW
• Illuminance @ 2 m: 175844 lx
• Illuminance @ 3 m: 78153 lx
• Illuminance @ 5 m: 28135 lx
• Luminous Flux (Total): 3075 lm
• CRI: 73

Optical

• Beam Angle Min. (Circular): 38°
• Beam Angle Max. (Circular): 158°
• Zoom Type: Motorised
• Zoom Ratio: 1:5
• Frost: Yes
• Focus: Motorised

Control and Programming

• Control Mode: Built-in Program, DMX
• DMX Channels: 8, 16, 18
• Protocols: DMX
• Display: TFT

Dynamic Effects

• Dimmer: 0-100 %
• Strobe: 0-20 Hz
• Shutter: Yes
• Prism 1: 3-facet
• Prism Index & Rotate: Yes
• Colour System: Colour Wheel
• Dichroic Colour Wheel 1: 9 + Open
• Gobo System: Glass + Metal
• Gobo Wheel Index & Rotate: Yes
• Gobo Wheel 1: 7 + Open
• Gobo Wheel 2: 12 + Open

Movement

• Pan: 540°
• Tilt: 270°
• Pan/Tilt Resolution: 16-bit

Electrical Specifications and Connections

• Power Supply: 100-240 VAC 50-60 Hz
• Power Consumption: 200 W
• Fuse: 4 A
• Power Connector In: Power Pro Blue
• Power Connector Out: Power Pro Grey
• DMX Connector: XLR 3P In/Out
• DMX Connector In: XLR 3P
• DMX Connector Out: XLR 3P

Mechanical Specifications

• Length (mm): 165 mm
• Width (mm): 283 mm
• Height (mm): 435 mm
• Weight: 9.85 kg
• IP Rating: IP20 (indoor use only)
• Housing: Metal, PVC
• Colour: Black

Product Properties

• Cooling: Axial fan

Rigging

• Mounting Options: Quick-Lock
• Safety Attachment: Yes
• Safety Eyes: 1

Thermal Specifications

• Maximum Ambient Temperature: 45 °C

Included Items

• Included Cables: Power Pro Cable
• Included Rigging: Quick-Lock Bracket
