Showtec Phantom 100 Spot Movinglights Spot
  • -15%

Showtec Phantom 100 Spot

€985.00
€841.00 -15%
Tax included
Lowest price within the last 30 days: €841.00

Compact 100 W LED Spot Moving Head

Qty

In Stock

Delivery

Do You want Your order by Tuesday, 03/06/2025? Order within 0 hours and 7 minutes

Free shipping

Compare

wishlist

Showtec Phantom 100 Spot



The Showtec Phantom 100 Spot is a compact, yet powerful 100 watt LED Spot Moving Head including motorised focus and gobo- and colour wheels, suitable for indoor venues. It has more features than the Phantom 65, like a 6-facet circular & 5-facet linear rotating prism and a 12° - 17° manually adjustable zoom range. The Phantom 100 Spot creates stunning optical effects with 7 precise bi-rotating gobos. Its compact 11.3 kg design and Quick-Lock brackets are ideal for quick rigging on stage. The mid-range priced Phantom 100 with razor sharp light beams and spectacular gobos, deliver a high performance/value ratio.

  • Compact 100 W LED Spot Moving Head
  • 7 bi-rotating interchangeable gobos + open
  • 8 colours + white
  • Dual rotating 6-facet circular and 5-facet linear prism
  • Manually adjustable zoom

Specifications

Source

  • Light Source Type: LED
  • Light Source Quantity: 1
  • Light Source Power: 100 W
  • LED Colour Type: CW
  • Illuminance @ 5 m: 5500 lx
  • Luminous Flux (Total): 5500 lm

Optical

  • Beam Angle Min. (Circular): 12°
  • Beam Angle Max. (Circular): 17°
  • Zoom Type: Manual
  • Zoom Minimum: 12°
  • Zoom Maximum: 17°
  • Focus: Motorised

Control and Programming

  • Control Mode: Auto, DMX, Manual, Master Slave, Sound
  • DMX Channels: 10, 14
  • Protocols: DMX
  • Wireless: Optional
  • Display: LCD

Dynamic Effects

  • Dimmer: 0-100 %
  • Strobe: 0-20 Hz
  • Prism 1: 5-facet
  • Prism 2 6-facet
  • Prism Index & Rotate: Yes
  • Colour System: Colour Wheel
  • Colour Wheel Index & Rotate Yes
  • Dichroic Colour Wheel 1: 8 + Open
  • Gobo System: Glass + Metal
  • Gobo Wheel Index & Rotate: Yes
  • Gobo Wheel 1: 8 + Open
  • Gobo Size: 24 mm
  • Image Diameter: 20 mm

Movement

  • Pan: 540°
  • Tilt: 270°
  • Pan/Tilt Resolution: 16-bit

Electrical Specifications and Connections

  • Power Supply: 100-240 V AC 50-60 Hz
  • Power Consumption: 200 W
  • Fuse: 5 A
  • Power Connector In
  • Power Pro Blue: Power Connector Out
  • Power Pro Grey: DMX Connector
  • XLR 3P In/Out: DMX Connector In
  • XLR 3P: DMX Connector Out
  • XLR 3P

Mechanical Specifications

  • Length (mm): 325 mm
  • Width (mm): 210 mm
  • Height (mm): 420 mm
  • Weight: 11.3 kg
  • IP Rating: IP20 (indoor use only)
  • Housing: Metal, Plastic
  • Colour: Black

Product Properties

  • Cooling: Axial fan

Rigging

  • Mounting Options: Quick-Lock
  • Safety Attachment: Yes

Thermal Specifications

  • Maximum Ambient Temperature: 40 °C

Included Items

  • Included Cables: powerCON cable
  • Included Rigging: Quick-Lock Bracket

40077
