Omnitronic LH-061 PRO Dual DI Box passive

• 2 high-impedance signal inputs via two 6.3 mm jacks
• 2 low-impedance XLR outputs
• Converts 2 separate unbalanced line inputs (e.g. CD player, instruments) into 2 balanced XLR outputs, for connecting a mixer
• Switchable input attenuation: 0 dB, -20 dB, -40 dB
• Cables can be routed under the housing
• For application areas such as: Installation; mobile use; mobile djs / entertainer

Scope of delivery

• 1 x user manual
• 1 x device

• Frequency range: 15 - 30000 Hz
• Impedance: Input: 50 kOhm, Output: 600 Ohm
• Input attenuation: 0 dB, -20 dB, -40 dB; switchable
• Control elements: Groundlift selector, Input sensitivity switch
• Connections: Input: 2 x 6.3 mm jack socket (mono) mounting version, Output: line via 2 x 3-pin XLR, Link: 2 x 6.3 mm jack socket (mono) mounting version
• Max. level: Output: +6 dBu
• Color: Black
• Dimensions: Width: 13.3 cm, Depth: 11.5 cm, Height: 5.4 cm
• Weight: 0.61 kg
