DAS ACTION-515 Passive Speakers
  • -21%

DAS ACTION-515


€685.00
€543.00 -21%
Tax included
Lowest price within the last 30 days: €543.00

Passive system, 300 W, 12", 2-way wide range, 90×60 adjustable speaker, black


Out of Stock

Free shipping


wishlist

DAS ACTION-515



ACTION-512 is a passive system designed to offer great versatility of use, from fixed installations to portable PA applications. Thanks to its 90º x 60º rotatable speaker, the ACTION-512 can be used in a horizontal position, both as a stage monitor and in front fill installations, offering flexibility in a wide variety of applications.

The system features a 12" transducer (model 12MI) and an M-34 compression driver for high frequencies, delivering 300 W RMS and up to 1200 W peak power. Constructed from birch plywood and coated with a durable ISO-flex finish, the ACTION-512 offers exceptional durability and ruggedness, making it the ideal choice for demanding applications.

For optimal and long-lasting performance, we recommend using DAS Audio amplifiers and processors, which include presets and limiters specific to the passive versions of the ACTION-500 series.

Specifications

Performance

  • Frequency range (-10 dB) 50 Hz – 20 kHz
  • Horizontal coverage (-6 dB) 90º
  • Vertical coverage 60º
  • Nominal impedance 8 ohms
  • RMS power 300 W
  • Peak power 1200 W
  • Axial sensitivity 1W/1 m 96 dB SPL
  • Maximum peak SPL at 1 m 131 dB

Connectors

  • Audio input connector 1 x speakON NL4
  • Audio output connector 1 x speakON NL4

Enclosure

  • Enclosure construction Birch plywood
  • Enclosure geometry Trapezoidal
  • Mounting Mounting points M10
  • Finish ISO-flex paint
  • Color
  • Dimensions (H x W x D) 620 x 385 x 380 mm 24.4 x 15.2 x 15.0 inches
  • Net weight 19.0 kg (41.8 lb)

Components

  • LF driver 12MI
  • HF driver M-34
  • Horn/wave guide BC-916


ACTION-515

Data sheet

Woofer inch
12"
