Datavideo SE-4000 Production Mixers & Switchers
  • -26%
  • New

Datavideo SE-4000

€13,857.00
€10,313.00 -26%
Tax included
Lowest price within the last 30 days: €10,313.00

12 Inputs UHD videoswitcher (split unit)

Out of Stock

Free shipping

Compare

wishlist

Datavideo SE-4000



The SE-4000 is an 8-inputs (8 x 12G-SDI+ 4 x HDMI)digital live production video switcher that supports true 4K 60/50p video resolution, with a variety of video inputs and outputs. Crosspoint assignment (XPT) in the signal routing matrix provides the ability to route any physical input and output to any of the available buttons.

With an intuitive interface on the 5 LCD touch panel, it is very easy to use and configure. The SE-4000 switcher also has powerful effects, such as Chroma Key, Luma Key, DSK, PIP, DVE, Wipe Generator, still store and inserting the logo.

  • Video standard: 4K and HD
  • Video format
  • Input: 3840x2160p: 60/59.94/50/30/29.97/25/24/23.98 - 1080p: 60/59.94/50/30/29.97/25/24/23.98 - 1080i: 60/59.94/50, 720p: 60/59.94/50 - VG A, XGA (1024 x 768), SXGA (1280 x 1024), - UXGA (1600 x1200), WUXGA (1920 x 1200)
  • Output: 3840x2160p: 60/59.94/50/30/29.97/25/24/23.98 - 1080p: 60/59.94/50/30/29.97/25/24/23.98 - 1080i: 60/59.94/50, 720p: 60/59.94/50
  • Video processing
  • SDI: 4:2:2 10-bit
  • HDMI: YUV 4:2:2 10-bit, RGB: 4:4:4 8/10-bit
  • Input routable / crosspoint: yes
  • Video input: total 8 live inputs (select 8 from 12) - 8 x 12G-SDI - 4 x HDMI
  • Computer graphic interface: 4 via HDMI
  • Video output: 4 x 12G-SDI - 3 x HDMI - All assignable: Multiview, PGM, PVW, PGM+DSK, Clean PGM, Clean PVW, Input 1-12
  • Built-in multi-view monitoring out: HDMI and SDI assignable
  • Analogue audio input: 4 x analogue XLR
  • Analogue audio output: 2 x analogue XLR
  • Digital embedded audio support: input 4 channels, output 4 channels
  • Audio delay calibration: up to 16 fields or 8 frames per channel
  • A+V Switching: yes
  • Chromakey: 4
  • Title creator: yes, CG-200 software free download
  • USK: 4 x Keyer support Chromakey/ Linear/ Luma Key
  • DSK: 2 x DSK support Lumakey and Linear key (Key / Fill)
  • Picture in Picture (PiP): 2
  • Logo insertion: 2
  • Still store: 999+
  • Effects: DVE, FTB, Cut, 32 wipe with border
  • Transition preview: full transitions preview
  • Sync / Reference IN/OUT: built-in Genlock - support external sync with loop-thru
  • Tally output: 1 x D-sub 25-pin, dual color
  • PC remote control: DVIP (Ethernet)
  • Firmware update: Ethernet
  • Special features: 5 touchscreen display
  • Chassis: 2 units, 2U rack-mount mainframe
  • Dimension (L x W x H): 433 x 312 x 76 mm (switcher) - 432 x 252 x 88 mm (main unit)
  • Weight: 7.1 kg
  • Power: 12 VDC / 108 W
  • Operating temp. range: 0 ~ 40 °C
  • What's in the box: : 1 x SE-4000 Main Unit - 1 x SE-4000 Control Board - 2 x AD Switch 12 VDC - 2 x AC cord - 1 x Ethernet Cable - 12 x Screw - 2 x 2U Ear Rack

DTV-2200-4000
