MJPG: 3840 x 2160, 2560 x 1440 at 30/25 fps. 1920 x 1080, 1280 x 960, 1280 x 720 at 60/50/30/25 fps USB output - H.264: 3840 x 2160, 2560 x 1440 at 30/25 fps. 1920 x 1080, 1280 x 960, 1280 x 720, 640 x 480, 640 x 360 at 60/50/30/25 fps USB output -
YUY2/NV12: 1920 x 1080 at 5 fps. 1280 x 960 at 10 fps. 1280 x 720 at 15 fps. 640 x 480, 640 x 360 at 30/25 fps
PAL: 1/25 s - 1/10,000 s,
NTSC: 1/30 s - 1/10,000 s
Wide angle: 0.1 m - ,
Tele: 1.5 m -
Optical zoom: 12x
Digital zoom: 4x (Format
YUV: 1.5x)
Pan: -165° - 165°,
Tilt: -30° - 30° Focal length and
FOV: varifocal lens 3.4 mm - 40.8 mm. equivalent focal length 23.1 mm - 277.2 mm
Field of view: horizontal 80.5° - 7.6°, vertical 50.5° - 4.4°, diagonal 88.9° - 8.7° Focusing: automatic/semi-automatic, with focus area selection
MEMS Directionality: omnidirectional 360°
Pick-up distance: up to 5 m
Number of microphones: 2
Frequency response: 100 Hz - 8 kHz
Sensitivity: -32 +- 3 dBV/Pa
SNR: 70 dB(A)
Sampling frequency: 16 kHz / 32 kHz / 48 kHz
Image functions: adjust parameters such as exposure, white balance, DNR, contrast, sharpness, saturation, hue,
Range Audio functions: intelligent noise reduction (stable and transient), AGC, echo suppression, time-domain equalization, ambient noise suppression, voice enhancement
Intelligent functions: human body tracking and face focus
LED indicator: startup: steady flashing white. on: steady white. mute: steady red. off: no light
Communication method: wireless 2.4G (camera and remote control) Wireless communication distance: 10 m Dynamic range (WDR): min. 120 dB
USB interface: 1 x USB Type-C (audio and video), supports USB 3.0
Audio: 1 x TRS 3.5mm three-segment line input, 1 x TRS 3.5mm three-segment line output
Power interface: 12 VDC, Ø2.1 mm
System requirements: Windows 7/8/10/11 (1080p resolutions require at least Windows 8.1). Android 8.1+. Linux 4.14+. mac
Power supply: 12 VDC +- 25%, max. 16.6 W
Operating conditions: -10 °C - 45 °C (14 °F - 113 °F), max. humidity 90% (non-condensing)
Dimensions: 148.9 mm x 145.7 mm x 152.1 mm (5.86 x 5.74 x 5.99)
Packaging dimensions: 308 mm x 216 mm x 187 mm (12.13 x 8.5 x 7.36)
Weight: about 1185 g (2.61 lb.)
Weight with packaging: about 2705 g (5.96 lb.)
Package contents: camera (with lens cap) x 1, remote control x 1, power adapter (1.2 m, US/UK/EU plugs) x 1, power extension cable (3 m) x 1, USB 2.0 cable (4.5 m) x 1, bracket x 1, screws x 1, batteries x 2, compliance and safety manual x 1
