ARTECTA LED DIM-5 RDM

The Artecta LED DIM-5 RDM is an industrial-level DMX512 and RDM controller with DMX decoder and DMX master functions. The 5-channel DMX decoder is capable of delivering 8 A per channel at 12 to 24 V DC. Multiple DMX signal input and output ports are available including XLR, RJ45, and screw terminals.

The bi-directional RDM communication functionality enables the LED DIM-5 RDM to detect and display decoder information and determine the DMX address. A variety of features can be set via the numerical display and buttons, such as DMX address, output channel quantity, PWM output resolution (8 bit or 16 bit), PWM output frequency, the dimming curve value, and the DMX decoding mode.

You can choose between 10 PWM output frequencies ranging from 500 Hz to 35 kHz and gamma dimming curves between 0.1 to 9.9. In master mode, you can control RGB LED lighting with 8 levels of brightness, choose between 32 built-in programs for RGB static colours or dynamic colour-changing patterns, and 16 changing speed levels.

• 5-Channel LED DMX controller with RDM
• 3-Pin XLR, RJ45, and screw terminal in/outputs
• 12-24 V DC / 8 A per channel
• Adjustable PWM (500 Hz - 35 kHz)
• 32 Built-in programs
