840 LEDs 0.5 W SMD 5730 cold white (CW) 16 segments controlled separately
Frost filter electronic
Strobe effect
27 integrated show programs
Can be operated in 2; 3; 5; 7; 17; 23 CH mode
The device is cooled by passive convection cooling
Control via stand-alone; master/slave function; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Flicker-free
With mounting bracket
LCD display
Mains input and output for power linking up to 8 units
For application areas such as: Clubs/dancing school; stage; theater; rental; wedding/gala/events; mobile djs / entertainer
Silent operation
Application possibility: Suspended; on stand
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 150 W
Protection class: Protection class I
Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output: P-Con (gray), mounting version
Lamp type: LED lamp
LED type: 840 x 0.5 W SMD 5730 cold white (CW)
Flash rate: 1 - 30 Hz
DMX channels: 2; 3; 5; 7; 17; 23
DMX input: 3-pin XLR (M) mounting version
DMX output: 3-pin XLR (F) mounting version
Cooling: Passive convection cooling
Control: Stand-alone; master/slave function; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for: Light Captain
Projection: Flicker-free
Color temperature: 6300K
Attachment system: Mounting bracket
Display type: LCD display
Dimensions: Width: 30.5 cm, Depth: 14.5 cm, Height: 34.5 cm
