FUTURELIGHT WDS-CRMX Duo TX Wireless DMX Transceiver


€373.00
Tax included

Wireless DMX system 2.4 GHz - two transceivers with CRMX unit in 19" housing


Qty

In Stock

Free shipping


wishlist

FUTURELIGHT WDS-CRMX Duo TX Wireless DMX Transceiver



Transceiver, to be used as transmitter or receiver Adaptive frequency hopping ensures interference-free operation in the 2.4 GHz band Can receive and process up to 1024 DMX channels Can transmit up to 1024 DMX channels

  • Multicolored LED indicator
  • (19&Quot;) 48.3 cm rack installation 1 U

Control via CRMX by LumenRadio; W-DMX by wireless solution Operating range up to 600 m with line-of-sight Up to 10 transmitters can be operated in parallel without interference

  • Mains input and output for power linking up to 8 units
  • Scope of delivery
  • 1 X device
  • 1 X user manual
  • 1 X power cord
  • 1 X declaration of conformity
  • Power supply: 100-240 V AC, 50/60 Hz
  • Power consumption: 3 W
  • IP classification: IP20
  • Protection class: Protection class I
  • Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug
  • Power output: P-Con (gray), mounting version
  • Device fuse: T 1 A fuse serviceable
  • DMX channels: Input 1024, Output 1024
  • DMX input: 2 X 3-pin XLR (M) mounting version, 2 x 5-pin XLR (M) mounting version
  • DMX output: 2 X 3-pin XLR (F) mounting version, 2 x 5-pin XLR (F) mounting version
  • Control: CRMX by LumenRadio; W-DMX by wireless solution
  • Range: Range up to 600 m with line-of-sight
  • Carrier frequency: 2.4 GHz
  • Parallel mode: Max. 10 transmitter
  • Antenna gain: 3 DBi
  • Modulation: GFSK
  • Status LED: DMX, level meter, power
  • Color: Black
  • Housing design: (19") 48.3 Cm rack installation 1 U
  • Dimensions: Length: 48.3 cm, Depth: 14.0 cm, Height: 44 cm
  • Weight: 1.33 kg
