Datavideo DAC-45 Video Signal Converters
  • -26%
  • New

Datavideo DAC-45


€1,640.00
€1,219.00 -26%
Tax included
Lowest price within the last 30 days: €1,219.00

4K Up/Down Cross Converter


Out of Stock

Free shipping


wishlist

Datavideo DAC-45



4K up conversion: With built-in super resolution engine, users can now up-convert from SD 480 resolution all the way to 4K resolution with excellent image quality and sharpness.

Wide range conversion for great compatibility: Supports VGA/HDMI/SDI to 4K HDMI/3G-SDI multi-format up/down/cross conversion.

External audio embedding: RCA inputs allow audio to be embedded to the output of the video signal.

With the 3G-SDI system, it supports both 3G-SDI Level A/B input. Supports Black Burst and Tri-Level Sync for all inputs.

Built-in De-interlacer and Interlacer (I/P conversion) to avoid the dense misaligned horizontal lines on the video.

The DAC CENTER software allows adjustment of HDMI color space. Support of various resolutions and HDMI color space allow consumer laptops to be used in a professional workflow. Available RMK-1 rack allows two DAC-45 to be racketed in a 19 rack.

  • Conversion: VGA/HDMI/SDI to 4K HDMI/3G-SDI
  • Multi-format Up/Down/Cross
  • Video Inputs: 1x VG A, 1x HDMI, 1x HD/SD-SDI
  • 1X Reference Input
  • Video Outputs: 1x SDI, 1x HDMI
  • Audio Inputs: 2x RCA(Unbalanced Audio L/R), 2x SDI/HDMI Audio embedded
  • Audio Outputs: SDI embedded audio up to 8CH, 48 kHz, PCM audio
  • HDMI embedded audio up to 8CH, 48 kHz, PCM audio
  • Supported Video Input Formats: 2160p(23.98/24/25/29.97/30/50/59.94/60 Hz), 1080p(23.98/24/25/29.97/30/50/59.94/60 Hz),
  • 1080Psf(23.98/24/25/29.97/30 Hz), 1080i (50/59.94/60 Hz), 720p (50/59.94/60 Hz),
  • 625I, 576p, 576i, 525i, 480p, 480i, 1920 x 1080(60 Hz), 1280x720(60 Hz), 1600x1200(60 Hz), 1400x1050(60 Hz), 1366x768(60 Hz), 1280x1024(60 Hz), 1024x768(60 Hz), 800x600 (60 Hz)
  • Output Resolutions: 2160p(23.98/24/25/29.97/30/50/59.94/60 Hz), 1080p(23.98/24/25/29.97/30/50/59.94/60 Hz),
  • 1080Psf(23.98/24/25/29.97/30 Hz), 1080i (50/59.94/60 Hz), 720p (50/59.94/60 Hz),
  • 625I, 576p, 576i, 525i, 480p, 480i
  • Equalizer: Yes
  • Reclock: Yes
  • SDI Cable Drive: Yes
  • Dimension (L x W x H): 220 x 143 x 42 mm
  • Weight: 1 kg
  • Operating Temp. Range: 0~40 °C
  • Power: DC 12 V, 9.4W
  • What's in the Box: 1 x DAC-45
  • 1 X AD Switch DC 12 V
  • 1 X Thank You Card
