CYP PUV-2200PL-RX

PUV-2200PL-RX is an HDBase. T 2.0 LITE receiver capable of receiving uncompressed HDMI, HD audio, USB, IR, and RS-232 signals over a single Cat. 5e/6/7 cable up to 35 meters away.

It supports resolutions up to 4K and #64; 60 Hz (4:2:0) and the most popular audio formats, ensuring compatibility with HDMI 2.0, DVI 1.0, and HDCP 2.2/1.x. It integrates analog audio inputs and outputs, a microphone input, and advanced control functions for great flexibility in AV installations.

Po. H support allows direct power from the transmitter, simplifying cabling.

• Main features
• HDBase. T 2.0 compatible
• Supports UHD resolutions up to 3840 x 2160 and #64; 60 Hz (4:2:0, 8-bit) and 4096 x 2160 and #64; 60 Hz (4:2:0, 8-bit)
• Pass-through of LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream audio formats
• HDMI 2.0 and DVI 1.0 compatible
• Compliant with HDCP 2.2 and HDCP 1.x
• Simultaneous transmission of uncompressed data over a single Cat. 5e/6/7 cable up to 35 m
• 16-Bit Deep Color up to 1080p and #64; 60 Hz
• Supports Po. H power supply from the transmitter (48 V)
• User benefits
• Reduced cabling thanks to the simultaneous transmission of Audio, video, control signals, and USB on a single cable
• Simplified installation thanks to Po. H, eliminating the need for additional power supplies
• Compatibility with professional audio formats for integration into advanced AV systems
• Greater flexibility thanks to analog audio inputs/outputs and a microphone input
• Control management via IR, RS-232 and USB for interactive and corporate systems
• Areas of use
• Conference rooms and meeting rooms
• AV installations requiring HDMI reception up to 35 meters
• Corporate environments requiring USB and integrated control
• Systems with analog audio and microphone routing
• All applications with 4K and #64; 60 (4:2:0) transmission over Cat.5e/6/7 cabling
