Professional 2 M/E hardware panel with 40 input buttons on each row and 2 independent system control LCDs, one for each row. Get 8 LCDs for custom labels and each row includes a separate select bus.
4 PA zone outputs, independently switchable on the front panel
Output for low-impedance speakers (4-16 ohms)
SD card slot and USB port
FM tuner with auto scan
3 microphone inputs with separate level controls
Mic 1 with phantom power, priority circuit and echo effect
Mic 2 and 3 switchable mic/line
2 line inputs with separate level controls
1 line output
Siren and chime, adjustable
Treble and bass and master controls for the output signal
5-digit LED level meter
Mains operation and 24 V emergency power operation
2 U
Control via Bluetooth; IR remote control
Desktop console housing
For application areas such as: Installation; restaurants, bars and hotels; sports centres/gyms
Scope of delivery
1 x amplifier
1 x user manual
1 x declaration of conformity
1 x power cord
1 x antenna
1 x remote control
1 x battery
Power supply: 100-240 V AC, 50/60 Hz, Or, 24V
Power consumption: 120 W
Protection class: Protection class I
Output power: 60 W RMS
Power connection: Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided), Battery/battery pack (not included)
Battery: 1 x button cell 3.0 V CR2025 lithium manganese built-in
Impedance: Public address systems 100V; Public address systems 70V; 4-16 ohms
Connections: Input: microphone via 1 x 3-pin XLR, Input: mic/line via 2 x 6.3 mm jack socket (stereo) mounting version, Input: line via 2 x stereo RCA, Output: line via 1 x stereo RCA 0.774 V, Output: speaker via screw terminal
Equalizer: Master: 1 x 2-band tone control
Music format: MP3
Housing design: 2 U, Desktop console housing
Dimensions: Width: 30.3 cm, Depth: 22 cm, Height: 9.1 cm
