Featured Products

Omnitronic MPVZ-180.6 PA Mixing Amplifier 100 V Amplifiers
  • -24%

Omnitronic MPVZ-180.6 PA Mixing Amplifier

€328.00
€250.00 -24%
Tax included
Lowest price within the last 30 days: €250.00

6 Zone PA mixing amplifier adjustable zones, 180 W RMS

Qty

In Stock

Delivery

Do You want Your order by Monday, 06/07/2026? Order within 13 hours and 47 minutes

Free shipping

Compare

wishlist

Omnitronic MPVZ-180.6 PA Mixing Amplifier



  • Comfortable control of PA speakers via 6-zone technology
  • 6 PA zone outputs with separate 5-step level controls
  • Output for low-impedance speakers (4-16 ohms)
  • 2 rear microphone inputs (6.3 mm jack, unbal.)
  • 1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
  • All microphone inputs with separate level controls
  • 3 line inputs (stereo RCA) with separate level controls
  • 1 line output (stereo RCA)
  • Chime, switchable
  • Treble and bass control for the output signal
  • 7-digit LED level meter
  • Master control for the output signal
  • (19) 48.3 cm rack installation 2 U
  • Highly efficient air flow from front to rear
  • The device is cooled by temperature-controlled fan
  • For application areas such as: Installation; restaurants, bars and hotels; sports centres/gyms

Scope of delivery

  • 1 x amplifier
  • 1 x user manual
  • Power supply: 230 V AC, 50 Hz
  • Power consumption: 360.00 W
  • Protection class: Protection class I
  • Output power: 180 W RMS
  • Power connection: Fixed power supply cord with safety plug
  • Device fuse: 5 x 20 mm, T 2 A fuse replaceable
  • Frequency range: 80 - 16000 Hz
  • S/N ratio: 75 dB microphone, 85 dB line
  • THD: 0.5 % at 1 kHz
  • Cooling: Temperature-controlled fan , air flow from front to rear
  • Impedance: Public address systems 100V; 4-16 ohms; Public address systems 70V
  • Zone output: 6 adjustable zones
  • Circuitry: Class AB
  • Control elements: Power switch, Master control, level control per channel, tone control, regular talkover
  • Controls: Current limiting; short-circuit; power on/off transient; power on/off transient; Overvoltage; short-circuit
  • Status LED: Power, fault, level meter
  • Connections: Input: microphone via 1 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version), Input: microphone via 2 x 6.3 mm plug (unbal.), Input: line via 3 x stereo RCA 0.3 V, Output: line via 1 x stereo RCA, Output: speaker via screw terminal
  • Equalizer: Master: 1 x 2-band tone control mono
  • Material: Metal
  • Color: Black
  • Housing design: (19) 48.3 cm rack installation 2 U
  • Dimensions: Width: 48.3 cm, Depth: 38.5 cm, Height: 8.9 cm
  • Weight: 9.30 kg

80709781

Data sheet

Color
Black
Giorni di elaborazione
4
