DJI Neo

Technical Data

Aircraft

• Takeoff weight About 135 g
• Dimensions 130 × 157 × 48.5 mm (L×W×H)
• Maximum rate of climb
• 0.5 m/s (Cinema mode)
• 2 m/s (Normal mode)
• 3 m/s (Sport mode)
• Maximum rate of descent
• 0.5 m/s (Cinema mode)
• 2 m/s (Normal mode)
• 2 m/s (Sport mode)
• Maximum horizontal speed (almost at sea level, in the absence of wind)
• 6 m/s (Normal mode)
• 8 m/s (Sport mode)
• 16 m/s (Manual mode)
• Maximum takeoff altitude 2000 m
• Data acquired in a windless environment during takeoff from an altitude of 2000 m and a vertical climb of 120 m, using Sport mode and with battery level from 100% to 20%. The data is for reference only. Always pay attention to notifications in the camera view during flight.‌
• Maximum flight time
• About 18 min (17 min with winglets)*
• Each battery allows the drone to perform at least 20 takeoffs and landings from the palm of your hand for successive shots**
• ‌* Data acquired during forward flight at a speed of 2 m/s in a windless environment 20 m above sea level, with camera parameters set to 1080p/30fps, video mode deactivated and battery level from 100% to 0%. Results may vary depending on the environment, operating method, and firmware version.
• ** Data acquired after activating DJI Neo, with a fully charged battery and default settings, and using Circle, Climb, and Dronie modes. The data is for reference only.
• Stationary flight time
• Approximately 18 min (17 min with winglets)
• Data acquired in stationary flight in a windless environment at 20 m above sea level, with camera parameters set to 1080p/30fps, video mode deactivated and battery level from 100% to 0%. Results may vary depending on the environment, method of use and firmware version.
• Maximum flight distance
• 7 km‌
• Data acquired during forward flight at a speed of 8 m/s in a windless environment at 20 m above sea level, with camera parameters set to 1080p/30fps, video mode off and battery level from 100% to 0%. Results may vary depending on the environment, usage method, and firmware version.
• Maximum wind speed resistance
• 8 m/s (Level 4)
• Operating temperature
• From -10 °C to 40 °C
• Global navigation satellite system
• GPS + Galileo + BeiDou
• Hovering accuracy range
• Vertical:
• ± 0.1 m (with visual positioning)
• ± 0.5 m (with GNSS positioning)
• Horizontal:
• ± 0.3 m (with visual positioning)
• ± 1.5 m (with GNSS positioning)
• Internal memory
• 22 GB
• Class
• C0 (EU)

Camera

• Image sensor
• 1/2” image sensor
• Lens
• FOV: 117.6°
• Equivalent format: 14 mm
• Aperture: f/2.8
• Focus: from 0.6 m to ∞
• ISO range
• 100 – 6400 (automatic)
• 100 – 6400 (manual)
• Shutter speed
• Video: 1/8000 – 1/30 s
• Photo: 1/8000 – 1/10 s
• Maximum image size
• Photo 12 MP
• 4000 × 3000 (4:3)
• 4000 × 2256 (16:9)
• Photo modes
• Single shot, timed shot
• Photo format
• JPEG
• Video resolution
• Without EIS:
• 4K (4:3): 3840×2880 at 30 fps
• 1080p (4:3): 1440×1080 at 60/50/30 fps
• With EIS:
• 4K (16:9): 3840×2160 at 30 fps
• 1080p (16:9): 1920×1080 at 60/50/30 fps
• Vertical shooting
• 1080p (9:16) 1080×1920 at 60/50/30 fps
• Video format
• MP4
• Maximum video bit rate
• 75 Mb/s
• Supported file systems
• exFAT
• Color mode
• Normal
• EIS
• Supports RockSteady, HorizonBalancing stabilization and stabilization deactivation.*
• * When using a 16:9 aspect ratio, only RockSteady or HorizonBalancing can be activated. Stabilization is not available in 4:3 aspect ratio. When stabilization is deactivated, captured footage supports offline stabilization with Gyroflow.

Stabilizer

• Stabilization
• Single-axis (tilt) mechanical stabilizer
• Mechanical radius
• Tilt: -120° to 120°
• Controllable radius
• Tilt: -90° to 60°
• Maximum control speed (tilt) 100°/s
• Angular vibration range ±0.01°
• Image roll correction
• Supports correction of footage recorded on the drone
• Live correction is not available only when using the headset

Detection

• Detection type
• Downward visual positioning
• Downward
• Precise stationing range: 0.5 – 10 m
• Operating environment
• Downward:
• Definite non-reflective surfaces with diffuse reflectivity of >20% (e.g. walls, trees or people)
• Adequate lighting (lux > 15 in normal indoor lighting conditions)

Video transmission

• Video transmission system
• O4
• Image transmission quality (Live View)
• With DJI RC-N3 remote controller: up to 1080p/60fps
• With DJI Goggles 3 and DJI RC Motion 3/DJI FPV Remote Controller 3: up to 1080p/60fps
• Operating frequency
• 2.400 – 2.4835 GHz
• 5.170 – 5.250 GHz
• 5.725 – 5.850 GHz
• The permitted operating frequency varies according to the country and geographical area. For further information, refer to local laws and regulations.
• Transmitter power (EIRP)
• 2.4 GHz:
• < 26 dBm (FCC)
• < 20 dBm (CE/SRRC/MIC)
• 5.1 GHz:
• < 23 dBm (CE)
• 5.8 GHz:
• < 26 dBm (FCC)
• < 14 dBm (CE)
• < 26 dBm (SRRC)
• Communication band
• Max. 40 MHz
• Maximum transmission distance (without obstacles or interference)
• FCC: 10 km
• CE: 6 km
• SRRC: 6 km
• MIC: 6 km
• Data acquired in an outdoor environment free of obstacles and interference and shows the farthest communication range for one-way flights based on each standard. The maximum video transmission distance in actual flight scenarios is limited by the maximum flight distance of the drone. During flight, always pay attention to RTH notifications during live viewing.
• Maximum transmission distance (without obstacles, with interference)
• Strong interference (urban areas): approx. 1.5–3 km
• Medium interference (suburban landscape): approx. 3–6 km
• Low interference (suburban/marine): approx. 6–10 km
• Data is measured in accordance with FCC standards, in open areas free of obstructions and interference. Used for reference purposes only and does not guarantee actual flight distance.
• Maximum transmission distance (in the presence of obstacles, with interference)
• Low interference and obstruction from buildings: approx. 0 – 0.5 km
• Low interference and obstruction from trees: approx. 0.5–3 km
• Data is measured in accordance with FCC standards in spaces that are typically subject to low interference. This data is intended for reference purposes only and does not guarantee actual transmission distance.
• Maximum download speed
• Wi-Fi: 25 Mbps
• Data acquired in a laboratory environment with little interference, in countries/regions that support both 2.4 GHz and 5.8 GHz. Download speed may vary depending on current conditions.
• Lowest latency
• With DJI RC-N3 radio control: approx. 120 ms
• Depending on actual environmental conditions and mobile device.
• Maximum video bit rate
• 50 Mb/s
• Antennas Two antennas, 1T2R

Wi-Fi

• Protocol
• 802.11a/b/g/n/ac
• Operating frequency
• 2.400 – 2.4835 GHz
• 5.725 – 5.850 GHz
• The permitted operating frequency varies by country and geographical area. For more information, refer to local laws and regulations.
• Transmitter power (EIRP)
• 2.4 GHz:
• < 20 dBm (FCC/CE/SRRC/MIC)
• 5.8 GHz:
• < 20 dBm (FCC/SRRC)
• < 14 dBm (CE)
• Effective operating range
• 50 m
• Data acquired in an outdoor environment free from interference. Video transmission distance varies depending on the operating environment.

Bluetooth

• Bluetooth 5.1 protocol
• Operating frequency 2.400 – 2.4835 GHz
• The permitted operating frequency varies according to the country and geographical area. For more information, refer to local laws and regulations.
• Transmitter power (EIRP) < 10 dBm

Battery

• Capacity 1435 mAh
• Weight Approx. 45 g
• Nominal voltage 7.3 V
• Charging voltage (max.) 8.6 V
• Type Li-ion
• Energy 10.5 Wh
• Charging temperature 5 °C to 40 °C
• Charging time
• When using the two-way charging hub (maximum charging power 60 W): approx. 60 min to charge three batteries simultaneously from 0% to 100%
• When charging directly to the aircraft body (maximum charging power 15 W): approx. 50 min to charge from 0% to 100%

Battery charger

• Recommended battery charger
• DJI 65 W portable battery charger
• USB Power Delivery battery charger

Battery charging station

• Input
• 5 V, 3 A
• 9 V, 3 A
• 12 V, 3 A
• 15 V, 3 A
• 20 V, 3 A
• Output (during charging)
• 5 V, 2 A
• Type of charging
• 3 batteries charged simultaneously
• The number of batteries that can be charged simultaneously varies depending on the power of the charger used. A charger with a power rating higher than 45 W allows you to charge three batteries simultaneously, while a charger with a power rating lower than 45 W can only charge two batteries. Consult the charging protocols supported by the charger.
• Compatibility
• DJI Neo Intelligent Flight Battery

Storage

• Recommended microSD cards
• Does not support memory expansion with an external SD card

DJI RC-N3 remote control

• Maximum operating time
• Without charging any mobile device: 3.5 hours
• When charging a mobile device: 1.5 hours
• Operating temperature
• From -10 °C to 40 °C
• Charging temperature
• From 5 °C to 40 °C
• Charging time
• 2 hours
• Charging type
• 5 V, 2 A
• Battery capacity
• 2600 mAh
• Weight
• Approximately 320 g
• Dimensions
• 104.2 × 150 × 45.2 mm (L×W×H)
• Operating frequency
• 2.400 – 2.4835 GHz
• 5.170 – 5.250 GHz
• 5.725 – 5.850 GHz
• The permitted operating frequency varies by country and geographical area. For more information, refer to local laws and regulations.
• Transmitter power (EIRP)
• 2.4 GHz:
• < 33 dBm (FCC)
• < 20 dBm (CE/SRRC/MIC)
• 5.1 GHz:
• < 23 dBm (CE)
• 5.8 GHz:
• < 33 dBm (FCC)
• < 14 dBm (CE)
• < 30 dBm (SRRC)

Package contents

• DJI Neo × 1
• Intelligent Flight Battery × 1
• Propeller guards (pair) × 1
• Spare propellers (pair) × 1
• Stabilizer protection × 1
• PD cable type C to type C × 1
• Screwdriver × 1
• Spare propeller screw
